What You Need - modway Nexus EEI-6283 Assembly Instructions Manual

Read through all of
the instructions
before starting
Approx. 60 minutes
assembly time
2 people recommended
for assembly
Furniture components:
Top Panel
1 x1
2 Bottom Panel x1
3 Side Panel - L x1
4 Side Panel - R x1
5
Center Panel - L x1
6 Center Panel - R x1
7 Back Panel x1
8 Shelf Panel x2
Body Support
9 x2
Provided hardware:
A1 Cam Lock
A2 Minifix Screw
Plastic Cap
A3
Plastic Cap
A4
B Wood Dowel M8 x 30mm
CSK Cap Wood Screw
C
M6 x 60mm
Allen Key M4
D
E C.B Screw M3.5 x 16mm
F C.B Screw M4 x 25mm
G C.B Screw M4 x 38mm
H Handle 209 Knob
Missing parts or hardware? Need assistance?
Contact us before returning your item. We're here to help!
609.256.9000 • cs@modway.com
Care instructions are
listed in the last step
of this manual
Make sure you have all
parts and components
before discarding any
packing materials
10 Drawer Front x3
11 Drawer Back x3
12 Drawer Side - L x3
13 Drawer Side - R x3
Drawer Bottom
14 x3
Drawer Support
15 x3
16 Door Panel x2
Metal Leg
17 x2
Metal Leg Support
18 x2
x24 I1
x24 I2
J
x12
x12 K
x22 L
x12 M
x1 N1
x70 N2
x5 O
x12 P
x5
Only use hand tools to assemble this item. Do not use power tools.
Do not tighten bolts or screws completely until all hardware is lined up
and inserted into the holes.
Do not over-tighten screws and bolts to avoid stripping the hardware
or cracking the item.
Assemble your item on a flat, carpeted area, with plenty of space to work.
This will prevent damage and scratches to your floors or the item while
you're assembling the product.
Keep all components and packaging out of reach of children or animals
to avoid risk of choking or suffocation.
3
16
17
11
12
13
10
H
14
15
Stud x10
Stud Screw x10
JCBC Screw M6 x 35mm x10
JCBC Screw M6 x 50mm x4
Metal Shelf Support
x8
Soft Closing 5/8 Hinges
x4
12" Drawer Slide - L/R
x6
12" Drawer Slide - L/R
x6
Metal Leg
x1
Anti - Tipping Kit
x1
1
9
5
8
8
16
H
H
18
O
x3

What You Need:

Phillips Head Screwdriver
7
9
6
4
2
17
Hammer
PAGE 2 OF 15
