What You Need - modway MOD-7134 Assembly Instructions

et' g t ta te !
Read through all of
the instructions
before starting
Approx. 30 minutes
assembly time
2 people recommended
for assembly
Furniture components:
1
Headboard
2
Side Rail
3
Footboard
4
Center Rail
Center Support Leg
5
Bed Leg
6
7
Slat
Provided hardware:
A
Allen Key M4
B
Allen Key M5
C
JCBC Bolt M6 x 40mm
Missing parts or hardware? Need assistance?
Contact us before returning your item. We're here to help!
609.256.9000 • cs@modway.com
Care instructions are
listed in the last step
of this manual
Make sure you have all
parts and components
before discarding any
packing materials
x1
x2
x1
x2
x6
6
x4
x15
D
x1
E
x1
x12 F
Only use hand tools to assemble this item. Do not use power tools.
Do not tighten bolts or screws completely until all hardware is lined up
and inserted into the holes.
Do not over-tighten screws and bolts to avoid stripping the hardware
or cracking the item.
Assemble your item on a flat, carpeted area, with plenty of space to work.
This will prevent damage and scratches to your fl oors or the item while
you're assembling the product.
Keep all components and packaging out of reach of children or animals
to avoid risk of choking or suff ocation.
1
7
6
2 4
5
5
5
5
5
Wood Screw
x4
M4 x 20mm
Wood Screw
x16
M4 x 25mm
Wood Screw
x4
M4 x 35mm
2
4
3
6
5
6

What you need:

Phillips Head Screwdriver
Phillips
