What You Need - modway Kurtis EEI-6233 Assembly Instructions Manual

Read through all of
the instructions
before starting
Approx. 60 minutes
assembly time
2 people recommended
for assembly
Furniture components:
1 Top Board
2 Bottom Board
3 Side Board Left
4 Side Board Right
5 Center Board
6 Adjustable Shelf
7 Frame Door
8 Back Board
LC15A2 Leg
Provided hardware:
A Cam Bolt Ø6 x 35 mm
B
Cam Lock Ø15 mm
C Wood Dowel Ø8 x 30 mm
D Screw M 7 x 50 mm
E Screw M 3.5 x 13 mm
F Screw Cap Ø15 mm
G
Allen Key
H Wedge
I Screw M 3.5 x 15.5 mm
Missing parts or hardware? Need assistance?
Contact us before returning your item. We're here to help!
609.256.9000 • cs@modway.com
Care instructions are
listed in the last step
of this manual
Make sure you have all
parts and components
before discarding any
packing materials
x1
x1
x1
x1
x1
x2
x2
x1
x4
x6 J
K
x6
x12 L
x6
M
x16 N
x6 O
PM2
x2
x10 US90
x10
Only use hand tools to assemble this item. Do not use power tools.
Do not tighten bolts or screws completely until all hardware is lined up
and inserted into the holes.
Do not over-tighten screws and bolts to avoid stripping the hardware
or cracking the item.
you're assembling the product.
Keep all components and packaging out of reach of children or animals
3
6
7
LC15A2
Shelf Pin x8
Silicon Bumper x4
Screw M 4.5 x 12.5 mm x16
Screw M 6 x 12.5 mm x10
Sliding Top x4
Sliding Bottom x4
Mounting Plate x4
Anti-De ection Bar x1
1
8
5
6
7
2
LC15A2

What you need:

Phillips Head Screwdriver
Phillips
4
PAGE 2 OF 8
