What You Need - modway Fortitude EEI-6523 Assembly Instructions Manual

Read through all of
the instructions
before starting
Approx. 45 minutes
assembly time
1 people recommended
for assembly
Furniture components:
1 Top Board
2 Bottom Board
3 Bar Side 1
4 Bar Side 2
5 Back Board
Provided hardware:
A Cam Bolt Ø6 x 35 mm
B
Cam Lock Ø12 mm
C Cam Lock Ø15 mm
D Wood Dowel Ø6 x 30 mm
E Screw M 4.5 x 12.5 mm
F Screw Cap Ø15 mm
G
PVC Sheet
LM14A1 Leg Metal
Missing parts or hardware? Need assistance?
Contact us before returning your item. We're here to help!
609.256.9000 • cs@modway.com
Care instructions are
listed in the last step
of this manual
Make sure you have all
parts and components
before discarding any
packing materials
x1
4
x1
x2
x16
x1

What you need:

x8
x4
Phillips
x4
x6
x16
x4
x2
x4
Only use hand tools to assemble this item. Do not use power tools.
Do not tighten bolts or screws completely until all hardware is lined up
and inserted into the holes.
Do not over-tighten screws and bolts to avoid stripping the hardware
or cracking the item.
you're assembling the product.
Keep all components and packaging out of reach of children or animals
1
5
3
3
2
Phillips Head Screwdriver
4
PAGE 2 OF 6
