A
PPENDIX
P
ROTECTOR
A 48.00
External Depth
B 31.7, 37.7, or 43.7
C 38.25
Internal Depth
D 24.00, 30.00, or 36.00
Filler Panel
E 8.00, 14.00, or 20.00
Duct C/L
Spacing One Duct
NOTE: See Chapter 3 for Dimension E.
DIM "A"
Hood Size
24" Depth
3ft 30" Depth 36.00
36" Depth
24" Depth
4ft 30" Depth 48.00
36" Depth
24" Depth
5ft 30" Depth 60.00
36" Depth
24" Depth
6ft 30" Depth 72.00
36" Depth
24" Depth
7ft 30" Depth 84.00
36" Depth
24" Depth
8ft 30" Depth 96.00
36" Depth
Product Service 1-800-522-7658
B
XL D
4' 5'
60.00 72.00
50.25 62.25
C/L C/L
One Duct One Duct
DIM "B" DIM "C" DIM "D"
31.7 24
37.7 26.25 30
43.7 36
31.7 24
37.7 38.25 30
43.7 36
31.7 24
37.7 50.25 30
43.7 36
31.7 24
37.7 62.25 30
43.7 36
31.7 24
37.7 74.25 30
43.7 36
31.7 24
37.7 86.25 30
43.7 36
IMENSIONS
XL Model Widths
6' 8'
96.00 120.00
86.25 110.25
48.00 50.00
Two Ducts Two Ducts
Figure B-1
10' 12'
144.00 192.00
134.25 182.24
62.00 48.00 Four
Two Ducts Ducts
43
16'
