prestige
Excellence
Indirect Water Heater
Part 2 of 2
* I N S
T
* I N S
T
WARNING
IMPORTANT
Revised 3/6/08
A
L
L
A
T
I O N
A
L
L
A
T
I O N
M
A
M
A
•
Before proceeding with installation and operation, read entire manual care-
fully. Failure to do so can cause injury or property damage.
•
When receiving the PRESTIGE Excellence, any claims for damage or
shortage in shipment must be filed immediately against the transporta-
tion company by the consignee.
•
Warranty Registration Card must be filled out by the customer and mailed
within thirty (30) days of installation in order to gain warranty coverage.
•
Retain and affix this manual near the water heater for future reference
•
Installation and service should only be performed by a qualified installer or
service technician.
•
Installations and service should be performed by a license plumber or gas
fitter in the Commonwealth of Massachusetts.
A
N D M
A
I N
A
N D M
A
I N
N U
A
L
N U
A
L
T
E N
A
N C E *
T
E N
A
N C E *
2007-19 Manual Prestige Excellence_IWH
