TriangleTube Cardinal 30 Installation & Maintenance Manual

Technical Specifications
Installation &
Maintenance Manual
30 - 4 0 - 50 - 6 0 - 80 - 10 0
INDI RECT FI RE D WATER HEATE R
WARNING
This document is intended to be used
by a factory trained and qualified
heating contractor or service technician
only. Read all Instructions within this
document and within the relevant Boiler
Installation and Maintenance Manual
before proceeding. It is recommended
to follow the procedures in the steps
given. Skipping or missing procedural
steps could result in substantial property
damage, serious injury, or death.
• When receiving the CARDINAL unit, any claims for damage or shortage in shipment must be filed
immediately against the transportation company by the consignee.
• Customer must register unit within sixty (60) days of installation in order to gain warranty coverage.
See Warranty Card for details.
• Leave all documentation received with appliance with the owner for future reference.
• Installation and service should only be performed by a qualified installer or service technician.
• Installations and service should be performed by a licensed plumber or gas fitter in the Common-
wealth of Massachusetts.
A1009090-661A0500_EN ■ A - 2023
CTMAN02
Low Lead Content
NSF/ANSI 372
• The heat transfer medium must be
water or other nontoxic fluid hav-
ing a toxicity rating or class of 1, as
listed in Clinical Toxicology of Com-
mercial Products, 5th edition.
• The pressure of the heat transfer
medium must be limited to a max-
imum of 30 psig by an approved
safety or relief valve.
NOTICE
CAUTION
O R I G I N A L
I N N O V A T O R S
T H E
