Pandora Camper v3 is a car service-security system built for motorhomes with on-board voltage of
12V. It is a complex engineering solution, which includes unique and modern technological software
and hardware solutions.
When building the Pandora Camper v3 we were using the most up-to-date electronics from
best manufacturers. The device is built using high-precision mounting and control machinery, thus
we guarantee highest possible quality, reliability and stable technical characteristics for the whole
operation period.
The Pandora Camper v3 has a cryptographically strong authorization code with unique dialog
algorithm and individual encryption key on every device. It guarantees protection form electronic
hacking for the whole operation period.
The system is built for your convenience: it's ergonomic, reliable, has the highest security and service
characteristics, 3 years unconditional warranty and free service and support. We are happy to provide
any support we can – feel free to use our online support.
!
WARNING! It's strongly recommended to install a security system by the skilled
automotive technician! The installation must be performed according to the provided technical
documentation, installation guides and schemes. The functionality and features of the system
depend on its correct installation/configuration and/or the specifics of the vehicle.
This device has limited external factors resistance. It should not be subjected to water beyond occasional splatter, or operated in
temperatures outside -40 to +85° C range. All system components must be installed only in a car interior.
The base unit and radio tags fulfil with the IP40 category of protection against water.
Our web-site: pandorainfo.com
Customer support: support@pandorainfo.com
Pandora would like to thank you for choosing
our service-security system Pandora Camper
Product is in conformity with Electromagnetic Compatibility
Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Camper v3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Pandora Camper v3

  • Page 1 Pandora would like to thank you for choosing our service-security system Pandora Camper Pandora Camper v3 is a car service-security system built for motorhomes with on-board voltage of 12V. It is a complex engineering solution, which includes unique and modern technological software and hardware solutions.
  • Page 2: Table Of Contents

    Table of contents General information Control the system by a phone System set Read before using Changing settings via a phone PIN-codes of the system Online service and mobile application Owner’s personal card External VALET button Control the system System modules layout Base unit Arming Information signals of the system...
  • Page 3: System Set

    System set Read before using 1. User manual Carefully read this manual before starting installation and using the security-service system. Pay attention to text marked with 2. Owner’s personal card 3. Remote control 4. Radio tag he securiTy and TelemeTric sysTem is a complex Technical producT ysTem insTallaTion and configuraTion musT be carried ouT only by a skilled professional 5.
  • Page 4: External Valet Button

    PIN-codes of the system External VALET button The “Secret PIN-code” An external VALET button with a two-color status LED indicator is placed CANNOT BE CHANGED (is written on the “Owner’s personal card” inside a vehicle (see the system modules layout) The button is used for The “Service PIN-code”...
  • Page 5: Base Unit

    Hydronic 1/2/3 heaters. DMS4 DMS9 DMS5 DMS10 Built-in Type C USB port – update and configuration of the system using a PC and Pandora Specialist. ore informaTion is available in andora pecialisT Base unit Built-in GSM modem (2G/3G/4G LTE) provides a connection with our online-service pandora-on.com and Pandora Connect (iOS and Android) mobile application, allows to control the system by a phone using DTMF-commands, voice and SMS notifications, automatic date and time detection.
  • Page 6: Information Signals Of The System

    Information signals of the system SOUND AND LIGHT SIGNALIZATION SIGNALS DESCRIPTION (sound / light) LED INDICATOR SIGNALS Arming 1х /1х SIGNALS DESCRIPTION Disarming 2х /2х THE SYSTEM IS ARMED Car search 5х /5х Short red flashes System is armed Alarm, PANIC mode 30 sec.
  • Page 7: System Functions And Modes

    SYSTEM FUNCTIONS AND MODES • “Parking light is not turned off” notification (status)* • Shock sensor (security zone – alarm and warning level) Security mode • Motion sensor (security zone – alarm level) • Tilt sensor (security zone – alarm level) The system confirms arming with 1х...
  • Page 8: Slave Mode

    Remote and automatic starts can only be used when the system is armed. While the system is in Slave mode can be implemented using analog connections or a digital protocol of a vehicle remote or automatic start mode, it keeps performing all security functions of all of the security zones excluding a shock sensor (the system can be configured to not disable the shock sensor during a remote his mode is disabled by defaulT for a digiTal proTocol ore informaTion in...
  • Page 9: Beach Mode

    ANTI-HI-JACK-1/2 modes When using the Beach mode system disarming is possible only by entering «Beach mode PIN-code» The Anti-Hi-Jack modes help to prevent aggressive seizure of a vehicle when authorization in case of or «Secret PIN-code» by a VALET button (see «Control the system in case of emergency») disappearance of authorization devices from the radio coverage zone when system is disarmed.
  • Page 10: Remote Control R-468Bt

    REMOTE CONTROL R-468BT Replacing the battery The CR2032 battery with a nominal voltage of 3V is used in the remote control. The battery should be The R-468BT remote control is designed to control and monitor a state of a security system and replaced if the sound and light indication is missing while pressing buttons.
  • Page 11: Firmware Update

    Firmware update Quick access functions of the remote control Use the Pandora Specialist (Android/iOS) mobile application to update the firmware System is disarmed • open the mobile app, go to the «Advanced mounting» -> «Bluetooth»; System is armed (no alarm events) •...
  • Page 12: Immobiliser Radio Tag

    IMMOBILISER RADIO TAG Light indication of SEND LED SIGNAL DESCRIPTION A radio tag is a device used to control a vehicle/system. The tag is also used as an authorization device for “Immobiliser/Anti-hi-Jack/HandsFree” modes. It works in the Bluetooth coverage zone. The radio 1 flash Arming/disarming tag has: a control button...
  • Page 13: Prompt Entry/Change Of The Main Owner Phone Number

    • Use the Pandora Specialist (Android/iOS) mobile application to update the firmware. Repeat the last message * Disable HandsFree • Open the mobile app Pandora Specialist, go to «Advanced mounting» -> «Bluetooth». Arming * Enable HandsFree arming • Press and hold the button...
  • Page 14 ‘Engine start’ , for instance, and add the number in the following format: Enabling/disabling automatic engine starts +XXXXXXXXXXX,123*,297* Pandora systems have a function of prompt disabling automatic engine start: where 1. Call the system number and wait for the answer.
  • Page 15: Changing Settings Via A Phone

    1. Call the system number. If the system is in PANIC mode, receive an emergency call. Wait for the Main owner's number -> # Changing guest PIN-code Phone Additional number settings settings answer. Additional owner's number -> # Entering as guest 2.
  • Page 16: Online Service And Mobile Application

    Internet access is installed in the system to provide After completing of the registration process, you can login to the online service via a computer’s web this functionality. browser or via the mobile app Pandora Connect. Use your previously created data: PASS ******** When approaching the vehicle or when Internet Login - your e-mail;...
  • Page 17: Control The System

    1 0 * Online-service Login to the PANDORA-ON.COM, when the system is online (there is an Internet connection) press the button on the control panel. PA N D O R A C A M P E R V 3...
  • Page 18: Activating Stay Home Mode

    To disarm the system without siren signals dial the command. Online service Login to the PANDORA-ON.COM, when the system is online (there is an Internet connection) press the button on the control panel. PA N D O R A C A M P E R V 3...
  • Page 19: Unlocking The Trunk

    Locking/unlocking doors when ignition is on Mobile application Pandora Connect Open the mobile application. When the system is online (there is an Internet or Bluetooth connection), press and hold the button on the control panel until the scale is fully loaded.
  • Page 20: Remote Engine Start

    Remote engine start Online service • To start the engine, login to the PANDORA-ON.COM (when the system is online there is an Internet If the system is prepared for remote start, use one of the methods described below to start the connection), press the START ENGINE button on the control panel.
  • Page 21 Owner’s personal card. • To deactivate Service mode dial the DTMF command. Mobile applications Pandora Connect To activate/deactivate Service mode, open the mobile application. When the system is online (there is an Internet or Bluetooth connection), press and hold the button on the control panel until the scale is fully loaded.
  • Page 22: Control The System In Case Of Emergency

    CONTROL OF THE SYSTEM IN CASE OF EMERGENCY Owner’s personal card External VALET button valeT emove The proTecTive layer carefully o noT he exTernal buTTon is placed in The inTerior efore using emergency sysTem conTrol check The sysTem and vehicle conTrol devices check a baTTery Turn on a «s...
  • Page 23: Emergency Disarming

    • Enter the fourth digit • Press the button the number of times equal to the fourth digit. Pauses OPTION №2 – EMERGENCY DEACTIVATION OF ANTI-THEFT FUNCTIONS between presses should not exceed 1 second. Each pressing will be confirmed with a simultaneous This method is used for a permanent deactivation of the anti-theft functions.
  • Page 24: Additional Devices

    • integrated “CALL/SOS” for arming/disarming, driver call and communication device designed to control a security system. The tag emergency notifications; can be used as an owner authorization device. • Integrated PANDORA security mode status LED. 868mh /128b | 2.4g (ble 4.2) |...
  • Page 25: Warranty Obligations

    WARRANTY OBLIGATIONS Manufacturer guarantees correct operation of the service-security system if exploitation, installation, storage and transportation conditions described in this manual were met. The system should only be used according to installation scheme and user manuals. The system is meant to be installed by the professional car electronics installers. The installer should fill in installation certificate that is included in this manual.
  • Page 26: Installation Certificate

    Car specifications: Car model____________________________________________ Type ____________________________ Id number (VIN)_______________________________________________________________________ Registration number____________________________________________________________________ Security system specification: Model Pandora Camper v3 Serial number_________________________________________________________________________ Service center name, full address and installer’s stamp ____________________________________________________________________________________ ____________________________________________________________________________________ Signature_____________________/___________________________________/...
  • Page 27: Acceptance Certificate

    ACCEPTANCE CERTIFICATE Model Pandora Pandora Camper v3 is in conformity with Electromagnetic Compatibility Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC. Serial number ______________________________ Date of production__________________________ Responsible person’s signature (stamp) Packager_____________________________________________________________________________ Signature (personal stamp) _____________________________________________________________________________________ WARRANTY CARD Model Pandora Camper v3 Serial number ________________________________________________________________________ Date of purchase «____»...
