Pandora DXL
Kia SOUL SK3 2019-
Installation manual
of Pandora service-security systems
for KIA SOUL SK3 2019-
model code 3232
Configuration: with start stop button and automatic gearbox
With original key and automatic gearbox
This instruction has the status of a recommendation
support@pandorainfo.com
pandorainfo.com
1
Advertisement
Related Manuals for Pandora 3232
Summary of Contents for Pandora 3232
- Page 1 Pandora DXL Kia SOUL SK3 2019- Installation manual of Pandora service-security systems for KIA SOUL SK3 2019- model code 3232 Configuration: with start stop button and automatic gearbox With original key and automatic gearbox This instruction has the status of a recommendation support@pandorainfo.com...
- Page 2 2. Connect a security system to PC via a USB cable. Windows (XP, 7, 8, 10) operating system must be installed on your PC. The PC must have a connection to the Internet. 3. Enter the programming mode on the system. 4. Run Pandora Alarm Studio (it can be downloaded from http://pandorainfo.com/support/alarmstudio- firmware/ 5.
-
Page 3: Connection Points
Pandora DXL Kia SOUL SK3 2019- Readable statuses, commands that are performed via CAN-bus Executable COMMANDS Readable STATUSES of car state Notes: 1* Analog connections is required for Remote engine start, Turbotimer and Program Neutral (Mechanical transmission) functions. 2* Fuel level in %... - Page 4 Pandora DXL Kia SOUL SK3 2019- Base unit location Possible location of the base unit –behind the fuse box. The unit must be securely fastened with double-sided tape and plastic ties. Connector ICU-G from the back side of the fuse box...
- Page 5 Pandora DXL Kia SOUL SK3 2019- Connector ICU-E from the back side of the fuse box Connector ICU-E from the back side of the fuse box Connector ICU-E from the back side of the fuse box Connector ICU-E from the back side of the fuse box...
- Page 6 Pandora DXL Kia SOUL SK3 2019- Connector ICU-E from the back side of the fuse box Connector ICU-E from the back side of the fuse box at the vehicles with the original key at the vehicles with the original key...
- Page 7 Pandora DXL Kia SOUL SK3 2019- Possible location of the siren Possible location of the siren Blocking of the starter Blocking oft he starter at the vehicles with the original key Blocking oft he starter at the vehicles with Start/stop buttоn...
- Page 8 Pandora DXL Kia SOUL SK3 2019- PIN entry Press the “valet” button the number of times equal to the first digit of the PIN code (in this case, 1 time). Each press will be confirmed with a green flash of the LED. Pauses between presses should not exceed 1 sec.
- Page 9 Pandora DXL Kia SOUL SK3 2019- Start the engine The engine must be warmed-up, RPM values should be same as normal idle RPM of the engine. Saving Press the valet button. The system will confirm recording with: 1 sound signal of the siren – success 3 sound signals of the siren –...
- Page 10 Pandora DXL Kia SOUL SK3 2019- Turn on ignition Learning The LED will be flashing green, then in case of: Success – the LED will be green and siren will sound a beep Fail – the LED will be red and the siren will sound 4 beeps.
