Summary of Contents for Pandora DWM-210
- Page 1 Smart digital window regulator control module with position memory USER INSTALLATION MANUAL pandorainfo.com...
- Page 2 Pandora would like to thank you for choosing our window regulator control module Pandora DWM-210. The Module DWM-210 is designed for sequential control 2 car win- dow regulators in two directions (to open and close), provided that the vehicle electric drives are installed. The module can be controlled by the “Up”...
- Page 3 This device has limited external factors resistance. It should not be subjected to water beyond occasional splatter, or operated in temperatures outside –40 to +80⁰C range. It is strongly advised to have professional car mechanic installing the module. Most features are highly dependent on competent installation. Our electronics is thoroughly tested for quality, so if a feature fails to pro- duce expected results, most likely the problem is in improper installation.
-
Page 4: Specification
SPECIFICATION PARAMETER VALUE Supply voltage, V 9...15 Current consumption, mA Maximum output current, A Positive or negative no less than Type of trigger impulse 500ms, digital code Pulse type on ‘Expansion’ output digital code Operation control Electromagnetic noise of the motors Operation time limit (for each 8±1 window),sec... - Page 5 MODULE SET Base unit DWM-210 Wires with a connector Screw ø 4,2х1 User installation manual Packaging FEATURES - Automatic windows closing when a car is armed; - The module memorize the position of the windows when a car is armed and automatically lets the windows down to the previous state if the parking lasted no more than 20 minutes.
-
Page 6: Module Operation
- The option to disable the alarm system sensors for the time of windows movement to exclude false alarm; The maximum efficiency of the module is achieved when it is used with Pandora car alarm systems. MODULE OPERATION The module can be controlled by a signal of ‘positive’ or ‘negative’... -
Page 7: Module Installation
(volume) sensor until all windows, doors and hatches are closed. Digital input (AUX) («Gray/Red») is intended to control the module by a code digital signal from the other devices: Pandora car alarm sys- tem, another DWM-210 module. MODULE INSTALLATION It should be installed in the car interior in place that is protected from moisture and dust. -
Page 8: Warranty Obligations
connections. All wiring must be insulated on the outside when instal- lation is finished. Throughout the metal bulkhead, wiring should pass only through special rubber bushings. The circuit diagram shows one possible mod- ule connection. WARRANTY OBLIGATIONS The manufacturer guarantees correct operation of the winder mod- ule if exploitation, installation, storage and transportation conditions described in this manual were met. - Page 9 • if the damage was caused with incorrect settings and parameter adjustment; • if module devices are replaced with any devices that are not recom- mended by the manufacturer; • if manufacturer sealing is broken; • if there is no properly filled warranty card and installation certificate. Warranty period is 3 years since the moment of purchase, but no more than 3,5 (three and a half ) years since the moment of production...
- Page 10 WIRING ASSIGNMENT SOCKET WIRE COLOR CIRCUIT CONTACT Module power supply +12V, 1A 11, 12 Window regulator power supply +12 V, 20A 7, 17 Black Ground White “Open windows” trigger input White/Red “Close windows” trigger input Gray Digital output Pink Status output Gray/Red Digital input (AUX) Yellow/Red...
-
Page 11: Acceptance Certificate
ACCEPTANCE CERTIFICATE Pandora DWM-210 is in conformity with Electromagnetic Compati- bility Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC. Serial number____ ________________________________________ Date of productio__________________________________________ Responsible person’s signature (stamp) Packager_________________________________________________ Signature _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _...
