To reset the PTC:

1. Temporarily remove wiring from output with tripped PTC (Fig. 1, pg. 4).
2. Eliminate the trouble condition (short circuit or overload).
3. Allow 1 minute for PTC to cool off (reset).
4. Re-attach wiring to the output (Fig. 1, pg. 4).
5. Power LEDs will illuminate indicating power has been restored to outputs (Fig. 1, pg. 4).
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or mois-
ture. This installation should be made by qualified service personnel and should conform to the
National Electrical Code and all local codes.
Power Supply Board
Red (DC)
ON
ON
OFF
OFF
ReServ Board
LED
Output LEDs
Low Battery
Shutdown
ReServ Unit
Audio Signal
Single Periodic Beep
Double Periodic Beep
Power Supply Board
Terminal Legend
L, G, N
– DC +
AC FAIL
NO, C, NC
BAT FAIL
NO, C, NC
+ BAT –
ReServ Board
Terminal Legend
Input – 24VDC +
N, P 1-2
N, P 15-16
ReServ5WP

LED Diagnostics:

Green (AC1)
ON
OFF
ON
OFF
LED State
ON
OFF
ON
OFF
ON
OFF

Audio Signal Diagnostics:

Unit Status
AC Fail.
Low Battery or No Battery.

Terminal Identification:

Function/Description
Connect 115VAC 60Hz to these terminals: L to hot, N to neutral.
24VDC output.
Form "C" dry contacts used to instantaneously signal the loss AC to local
annunciation devices.
With AC present terminals marked NO and C are open, NC and C are closed.
When loss of AC occurs, terminals marked NO and C are closed, NC and C are open.
Form "C" dry contacts used to signal low battery voltage or loss of battery voltage.
Under normal conditions terminals marked NO and C are open, NC and C are closed.
During a trouble condition terminals marked NO and C are closed, and NC and C are open.
Stand-by battery connections. Maximum charge current 0.7A.
Function/Description
24VDC input from power supply board.
12VDC outputs. N = Negative, P = Positive (Fig. 1, pg. 4).
24VAC outputs.
Power Supply Status
Normal operating condition.
Loss of AC. Stand-by battery supplying power.
No DC output.
Loss of AC. Discharged or no stand-by battery. No DC output.
Unit Status
Normal operating condition.
Loss of 24VAC and/or 12VDC output power.
Stand-by batteries are low.
Normal operating condition.
Loss of 24VAC and/or 12VDC output power.
Discharged stand-by battery.
Normal operating condition.
- 3 -
