Summary of Contents for Autonomous SmartDesk 5
- Page 1 Assembly Instructions Number of People 10-20...
-
Page 2: Table Of Contents
INSTRUCTION OUTLINE CAUTION INCLUDED PARTS ASSEMBLY GUIDE COLUMN ASSEMBLY FOOT ASSEMBLY SIDE BRACKET ASSEMBLY DRIVE SHAFT ASSEMBLY FRAME ASSEMBLY CABLE TRAY ASSEMBLY KEYPAD CONNECTION DESK FLIPPING USER MANUAL 11 - 12... -
Page 3: Caution
CAUTION READ AND FOLLOW ASSEMBLY INSTRUCTIONS CAREFULLY BEFORE USE. Keep kids and pets away during use. Unplug during storms or long unused periods. Keep desktop away from walls for ventilation. Keep the under-desk area (20"+) obstacle-free during use. Keep the desk in 0-40°C, away from dust and corrosives. -
Page 4: Included Parts
INCLUDED PARTS Desktop Power Adapter Keypad Rubber Pad Cable Management Tray Drive Shaft Cross Bar Hook Side Bracket Foot Pad Column Foot M6x12 Screws M6x10 Screws M6x35 Screws x 11 ST4x16 Screws Cable Clip Hex Screw Driver M6x16 Screws... -
Page 5: Assembly Guide
ASSEMBLY GUIDE COLUMN ASSEMBLY M6x10 Screws Hex Screw Driver Connect Cross Bar to the Columns Note: The motor is angled at 45 to optimize the lifting force Tighten 8 screws securely... -
Page 6: Foot Assembly
FOOT ASSEMBLY Hex Screw Driver M6x35 Screws Flip the Column upside down and insert the Feet Insert 8 screws & 4 Foot Pads... -
Page 7: Side Bracket Assembly
SIDE BRACKET ASSEMBLY Hex Screw Driver M6x12 Screws Attach Side Brackets to the Columns Insert 4 screws & 6 Rubber Pads... -
Page 8: Drive Shaft Assembly
DRIVE SHAFT ASSEMBLY Note: Lower both Columns to the lowest position before inserting the Drive Shaft Insert the Drive Shaft Insert the Drive Shaft into the first Column into the second Column The adjustment knob can be extended or retracted... -
Page 9: Frame Assembly
FRAME ASSEMBLY Hex Screw Driver M6x16 Screws Note: Place a Foam Pad under the Desktop to prevent scratches when installing Position the Frame on the Desktop, align the Side Bracket holes with the Desktop holes Insert 8 screws... -
Page 10: Cable Tray Assembly
CABLE TRAY ASSEMBLY ST4x16 Screws M6x10 Screws Hex Screw Driver Attach Cable Tray to the Frame & insert 3 screws Attach Keypad to the Desktop & insert 2 screws... -
Page 11: Keypad Connection
KEYPAD CONNECTION Connect the motor and power cords to the Keypad Secure all the cords with the Cable Clip... -
Page 12: Desk Flipping
DESK FLIPPING Note: Ensure all screws are tightened before flipping the desk. Keep the Foam Pad under the desktop to prevent scratches during the flip. Attach Hooks to Side Brackets... -
Page 13: User Manual
USER MANUAL User Interface Guide Reset 1) Press the down button until the desk reaches its lowest position. Release the down button and press it again for 5 seconds. 2) When the reset is complete, the display will show the starting height. The down button can then be released. - Page 14 Error Codes and Descriptions for Desk Keypad...
- Page 15 Any questions? Chat with our Customer Support team at www.autonomous.ai/help-center We're here to help!
