Summary of Contents for Autonomous SmartDesk 5
- Page 1 Assembly Guide Number of People 30-45...
-
Page 2: Table Of Contents
TABLE OF CONTENTS CAUTION INCLUDED PARTS ASSEMBLY GUIDE COLUMN ASSEMBLY SIDE BRACKET ASSEMBLY FOOT ASSEMBLY CENTER RAIL ASSEMBLY FRAME INSTALLATION CABLE TRAY ASSEMBLY DESK FLIPPING CABLE MANAGEMENT ACCESSORY INSTALLATION SETUP KEYPAD RESET INSTRUCTION HEIGHT ADJUSTMENT & MEMORY SETUP ANTI-COLLISION LEVEL SETTINGS... -
Page 3: Caution
CAUTION READ AND FOLLOW ASSEMBLY INSTRUCTIONS CAREFULLY BEFORE USE. Keep kids and pets away during use. Unplug during storms or long unused periods. Keep desktop away from walls for ventilation. Keep the under-desk area (20"+) obstacle-free during use. Keep the desk in 0-40°C, away from dust and corrosives. Do not disassemble without permission. -
Page 4: Included Parts
INCLUDED PARTS Desktop Power Cord Keypad Power Outlet Control Box Cable Tray Cable Organizer Hooks Columns Upper Tube Feet Side Brackets Center Rails Frames M6x10 Screws M6x14 Screws M6x12 Screws Zip Ties M4 Wrench M6x10 Hand Screws... -
Page 5: Assembly Guide
ASSEMBLY GUIDE COLUMN ASSEMBLY Attach Columns to the Frame Easily align the screw positions by inserting 4 screws (2.1) and 4 screws (2.2), without tightening Tighten screws (2.1) and screws (2.2) -
Page 6: Side Bracket Assembly
SIDE BRACKET ASSEMBLY Attach Side Brackets to the Frame Insert 2 screws... -
Page 7: Foot Assembly
FOOT ASSEMBLY Attach Feet to Columns Insert 4 screws... -
Page 8: Center Rail Assembly
CENTER RAIL ASSEMBLY Notch direction Attach Center Rails to the Frame, following the notch direction Insert 8 screws without tightening... -
Page 9: Frame Installation
FRAME INSTALLATION Place a Foam Pad under the Desktop to prevent scratches when installing With 2 people, position the Frame on the Desktop, align the Side Bracket holes with the Desktop holes Insert 6 screws... - Page 10 FRAME INSTALLATION Insert 2 screws Tighten 8 screws...
-
Page 11: Cable Tray Assembly
CABLE TRAY ASSEMBLY Assemble the Cable Tray to the Desktop Insert 4 screws Insert 2 hand screws... -
Page 12: Desk Flipping
DESK FLIPPING Note: Make sure all screws are tight, then flip upright. Keep the Foam Pad under the Desktop during flipping to prevent scratches. -
Page 13: Cable Management
CABLE MANAGEMENT Route the Keypad Cable through the Desktop Turn 2 hand screws to release the Cable Tray Plug Motor & Keypad Cords into the Control Box & secure them with the cable winders Plug the power cord into the Outlet &... -
Page 14: Accessory Installation
ACCESSORY INSTALLATION Attach the Cable Organizer to the Desktop & Hooks to the Side Brackets Attach the Upper Tube to a Column Note: The Power Cord should be put through the Upper Tube before attaching... -
Page 15: Setup Keypad
SETUP KEYPAD RESET INSTRUCTION Press & hold for 3 seconds Release when there is a "beep” sound to complete reset. -
Page 16: Height Adjustment & Memory Setup
HEIGHT ADJUSTMENT & MEMORY SETUP 29.5 Press to adjust the height Press and hold for 3 seconds until the display flashes, then press the memory to save Press to move the desk to the saved height... -
Page 17: Anti-Collision Level Settings
ANTI-COLLISION LEVEL SETTINGS The Anti-collision setting prevents damage and accidents by stopping the desk if it hits something, becomes uneven, or tilts. Press & hold for 5 seconds to enter setting mode Press to adjust sensitivity. For the smoothest operation, we recommend setting the anti-collision back to level 1. - Page 18 Any questions? Chat with our Customer Support team at www.autonomous.ai/help-center We're here to help!
