bar represents 10 % capacity. The topmost bar shows the
maximum capacity.
Example: Four ice-blue bars and one white bar are dis-
played. The state of charge is between 81 % and 90 %.
If capacity is low, both of the lower displays change colour:
Bar
2 × orange
1 × orange
1 × red
1 × red flashing
If the eBike battery is being charged, the topmost bar on the
battery charge indicator of the eBike battery (13) flashes.
The eBike battery's state of charge is also indicated outside
the eBike, by the LEDs on the eBike battery.
Selecting the Assistance Level
On the operating unit, you can set the level of assistance you
want the drive to provide you with while pedalling.
Mini Remote/Mini Remote Dropbar: Briefly press (< 1 s)
the buttons to increase assistance + (4) or decrease assist-
ance – (6) in order to increase or decrease the assistance
level accordingly.
System Controller: Briefly press (< 1 s) the mode button
(14) to increase assistance.
Press the mode button (14) for longer than 1 s to decrease
the assistance.
The assistance level can be changed at any time, even while
cycling, and is displayed in colour.
Level Notes
OFF Drive assistance is switched off. The eBike can
just be moved by pedalling, as with a normal bi-
cycle.
ECO Effective assistance with maximum efficiency,
for maximum range
TOUR Steady assistance, long range for touring
TOUR+ Dynamic assistance for natural, sporty cycling
eMTB Optimal assistance whatever the terrain, rapid
acceleration when starting from a standstill, im-
proved dynamics and top performance
SPORT Powerful assistance, for mountain biking and
for cycling in urban traffic
TURBO Maximum assistance even at a high cadence,
for sporty cycling
AUTO The assistance is dynamically adapted to the
riding situation.
RACE Maximum support on the eMTB racetrack; very
direct response and maximum "Extended
Boost" for the best possible performance in
competitive situations
CARGO Steady, powerful support for safely transport-
ing heavy weights
0 275 007 3RC | (17.02.2023)
Capacity
30 % to 21 %
20 % to 11 %
10 % to reserve
Reserve to empty
Level Notes
SPRINT Dynamic support according to cadence – for
athletic eGravel and eRoad cycling with rapid
sprints and frequent ascents
Note: The available modes depend on the respective drive
unit.
The designations and configuration of the assistance levels can be
preconfigured by the manufacturer and selected by the bicycle re-
tailer.
Adapting the Assistance Level
The assistance level can be adapted within certain limits us-
ing the eBike Flow app. This gives you the option of adjust-
ing your eBike to your personal requirements.
It is not possible to create a completely new mode. You can
only adjust the modes that have been enabled by the manu-
facturer or dealer on your system. This may be fewer than
four modes.
In addition, restrictions in your country may mean that it is
not possible to adjust a particular mode.
The following parameters are available for making adjust-
ments:
– Assistance in relation to the base value of the mode
(within the legal requirements)
– Drive response
– Top limit speed (within the legal requirements)
– Maximum torque (within the limits of the drive)
Note: Please ensure that your modified mode retains the po-
sition, name and colour on all on-board computers and con-
trols.
Interaction between the Drive Unit and Gear-
shifting
The gear shifting should be used with an eBike in the same
way as with a normal bicycle (observe the operating instruc-
tions of your eBike on this point).
Irrespective of the type of gear shifting, it is advisable that
you briefly reduce the pressure on the pedals when changing
gear. This will aid gear shifting and reduce wear on the
powertrain.
By selecting the correct gear, you can increase your speed
and range while applying the same amount of force.
Switching Bicycle Lights On and Off (Mini
Remote/Mini Remote Dropbar only)
Check that your bike lights are working correctly before
every use.
To switch on/off the bike lights, press and hold the bicycle
lights (4) button for more than 1 s.
Switching the Walk Assistance On and Off
The walk assistance makes it easier to push your eBike. The
maximum speed of the walk assistance is 4 km/h. The manu-
facturer can adjust the default so that it is lower and, if ne-
cessary, it can also be adjusted by the bicycle retailer.
