Altronix TROVE PLUS T3M77XK1V Installation Manual page 8

2.00" (50.8mm)
1.25" (31.8mm)
1.25" (31.8mm)
1" Conduit
3/4" Conduit
G
G
1.25" (31.8mm)
Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice.
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty
IIT3M77XKV Kit Series
- 8 -
Trove3 Enclosure Dimensions (H x W x D approximate):
36.12" x 30.125" x 7.06" (917.5mm x 768.1mm x 179.3mm)
7.12" (222.3mm)
1" Conduit
3/4" Conduit
1.07"
(27.2mm)
14.01" (355.9mm)
3/4" Conduit
1" Conduit
8.75" (222.3mm)
2"
(50.8mm)
9.5" (241.3mm) 9.5" (241.3mm)
1.78" (45.2mm)
1.25" Conduit 1.5" Conduit
2" Conduit
1.5" Conduit 1.25" Conduit
30.12" (768.1mm)
14.01" (355.9mm)
8.62" (219mm) 8.75" (222.3mm)
G10W
1.55" (39.4mm)
2" (50.8mm)
1" Conduit
3/4" Conduit
1.25" (31.8mm)
7.06" (179.3mm)
T3M77XKV Kit Series Installation Guide
