System Sensor FAAST LT-200 Setup Manual page 12

Table A3: Loop Based (Addressable) Versions
# PARAMETER
1 Maintenance Password
2 Current configuration number
3 Current configuration date
4 Channel 1 enabled
5 Channel 2 enabled
6 Sensor 1 enabled
7 Sensor 2 enabled
8 Daylight saving enabled
9 Daylight saving start date
10 Daylight saving end date
11 Disable time
12 Maintenance timeout
13 Trend log interval
14 Sensors blinking replicated
15 Both supplies monitored
16 Common chamber sensors
required for alarm
17 Sounder automatic cut-off time
18 Channel 1 alarm is latched
19 Channel 2 alarm is latched
20 Alarm delay
21 Auxiliary relay is used for channel 2
faults
22 Channel 1 label
23 Channel 2 label
24 Channel 1 fan speed mode
25 Channel 2 fan speed mode
26 Channel 1 manual fan speed
27 Channel 2 manual fan speed
28 Reference flow for channel 1
29 Reference flow for channel 2
30 High flow threshold for channel 1
31 High flow threshold for channel 2
32 Low flow threshold for channel 1
33 Low flow threshold for channel 2
34 Flow fault delay
35 Channel 1 filter due date
36 Channel 2 filter due date
37 General fault is latched
38 General fault delay
39 Pressure
40 Power restart alert time
41 Auxiliary relay set on low/high
temperature alert
42 Auxiliary relay set on external input
in not normal state
43 Auxiliary relay set on low power
alert / high power fault
44 Auxiliary relay set on flow fault
45 Auxiliary relay set on sensor
communication fault
46 Auxiliary relay set on power restart
alert
47 Auxiliary relay is latched
D200-100-01
PARAMETER RANGE
1111 - 9999
0..255
DD/MM/YY HH:MM:SS
YES/NO
YES/NO
YES/NO
YES/NO
YES/NO/AUTO
DD/MM HH:MM
DD/MM HH:MM
1..240 min
1..30 min or 0 (DISABLED)
1..240 min or 0 (DISABLED)
YES/NO
YES/NO
1,2
0 (Disabled), 5,10,15,...,600 s
YES/NO
YES/NO
0 ..240 s
YES/NO
16 char (ascii code from 32 to 127)
16 char (ascii code from 32 to 127)
Manual, Auto
Manual, Auto
0..10
0..10
32 – 65 litres/min
32 – 65 litres/min
-50% to +50%
-50% to +50%
-50% to +50%
-50% to +50%
0..240 s
DD/MM/YY
DD/MM/YY
YES/NO
0..240 s
68758 – 110000 Pa
0 (Alert disabled), 1..240 s, 255 (no
time limit)
YES/NO
YES/NO
YES/NO
YES/NO
YES/NO
YES/NO
YES/NO
12
1 Channel 1 Channel
1 Sensor 2 Sensor
3111 3111
1 1
* *
YES YES
X X
YES YES
X YES
NO NO
25/02 02:00 25/02 02:00
28/10 02:00 28/10 02:00
60 60
5 5
0 0
YES YES
NO NO
1 1
0 0
NO NO
NO NO
0 0
YES YES
"1" "1"
X X
Auto Auto
X X
X X
X X
45 litres/min 45 litres/min
X X
set to EN54-20 requirements (-20% - +20%)
X X
set to EN54-20 requirements (-20% - +20%)
X X
60 60
01/01/99 01/01/99
X X
NO NO
0 0
101325 101325
0 0
NO NO
NO NO
NO NO
NO NO
NO NO
NO NO
NO NO
2 Channel
2 Sensor
3111
1
*
YES
YES
YES
YES
NO
25/02 02:00
28/10 02:00
60
5
0
YES
NO
1
0
NO
NO
0
YES
"1"
"2"
Auto
Auto
X
X
45 litres/min
45 litres/min
As Above
As Above
60
01/01/99
01/01/99
NO
0
101325
0
NO
NO
NO
NO
NO
NO
NO
I56-3888-010
