# PARAMETER
44 Auxiliary relay set on flow fault
45 Auxiliary relay set on sensor
communication fault
46 Auxiliary relay set on power restart
alert
47 Auxiliary relay is latched
48 External input normal state
49 External input triggers fault
50 External input silences sounders
51 External input reset device
52 External input disables ASD
53 External input ASD disabling time
54 Pre-alarm delay
55 Pre-alarm and Alarm are in
cascade
58 Day start time
59 Day end time
60 Holiday day #1 date
...
79 Holiday day #20 date
80 Sounder activation mode
81 Day/night mode enabled
82 Monday is holiday
83 Tuesday is holiday
84 Wednesday is holiday
85 Thursday is holiday
86 Friday is holiday
87 Saturday is holiday
88 Sunday is holiday
89 Sensor 1 day alarm level
90 Sensor 2 day alarm level
91 Sensor 1 day pre-alarm level
92 Sensor 2 day pre-alarm level
93 Sensor 1 night alarm level
94 Sensor 2 night alarm level
95 Sensor 1 night pre-alarm level
96 Sensor 2 night pre-alarm level
97 Alarm mode
98 Sensor communication timeout
99 Remote output time for alarm
* Pre-alarm will be set to 70% of this Level 1 value.
D200-100-01
PARAMETER RANGE
YES/NO
YES/NO
YES/NO
YES/NO
OPEN, SHORT
YES/NO
YES/NO
YES/NO
YES/NO
1..1440 min
0 (OFF), 1..240 s
YES, NO
HH:MI
HH:MI
DD/MM
DD/MM
DD/MM
On Pre-alarm, On Alarm
YES/NO
YES/NO
YES/NO
YES/NO
YES/NO
YES/NO
YES/NO
YES/NO
1..9
1..9
1..9
1..9
1..9
1..9
1..9
1..9
Sensor alarm mode, module alarm
mode
0 (Disabled),1...240 s
50, 100,...10000ms
11
1 Channel 1 Channel
1 Sensor 2 Sensor
NO NO
NO NO
NO NO
NO NO
OPEN OPEN
NO NO
NO NO
YES YES
NO NO
60 60
0 0
NO NO
08:00 08:00
17:00 17:00
empty empty
empty empty
empty empty
Alarm Alarm
NO NO
NO NO
NO NO
NO NO
NO NO
NO NO
NO NO
NO NO
1* 1*
1* 1*
1* 1*
1* 1*
1* 1*
1* 1*
1* 1*
1* 1*
X X
X X
X X
2 Channel
2 Sensor
NO
NO
NO
NO
OPEN
NO
NO
YES
NO
60
0
NO
08:00
17:00
empty
empty
empty
Alarm
NO
NO
NO
NO
NO
NO
NO
NO
1*
1*
1*
1*
1*
1*
1*
1*
X
X
X
