Patriot Lighting MEC56MBK5LR Installation Manual

Hide thumbs

Table of Contents

Quick Links

Installation Guide

For model:

MEC56MBK5LR,

#355-0721

4009654

net weight of fan: 21.6 lb. (9.8 kg)

READ THESE INSTRUCTIONS AND

SAVE THEM FOR FUTURE USE

Need help?

Do you have a question about the MEC56MBK5LR and is the answer not in the manual?

Questions and answers

Summary of Contents for Patriot Lighting MEC56MBK5LR

Page 1: Table Of Contents
READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Installation Guide For model: MEC56MBK5LR, #355-0721 Table of Contents: Safety Tips. pg. 2 Unpacking Your Fan. pg. 3 Parts Inventory. pg. 3 Installation Preparation. pg. 4 Hanging Bracket Installation. pg. 4 Fan Assembly.
Page 2: Safety Tips
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.
Page 3: Unpacking Your Fan
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.
Page 4: Installation Preparation
3. Installation Preparation. blade edge To prevent personal injury and damage, ensure that the hanging location allows the blades a clearance of inches 7 feet 7 ft. (2.13m) from the floor and 30in. (76cm) from any (2.13 m) (76 cm) wall or obstruction.
Page 5: Fan Assembly. Pgs
5. Fan Assembly. stop pin set screw Remove hanging ball from downrod provided by loosening set screw on hanging ball. Remove pin and clip. Lower hanging ball and remove stop pin. hanging ball Then slide hanging ball off downrod. [Refer to diagram 1.] clip diagram 1...
Page 6 5. Fan Assembly. (cont.) With the hanging bracket secured to the outlet box and able to support the fan you are now ready to hang your fan. Grab the fan firmly with two hands. hanging bracket tab Slide downrod through opening in hanging bracket and let hanging ball rest on the hanging bracket.
Page 7: Wiring
7. Wiring. WARNING: Turn off circuit breakers to current ground fixture from breaker panel and be sure switch (green or bare) white supply wire is turned to the OFF position. black supply wire ground (green CAUTION: Be sure outlet box is properly grounded or bare) and that a ground wire (GREEN or Bare) is present.
Page 8: Blade Assembly
9. Blade Assembly. WARNING: To reduce the risk of serious bodily injury, DO NOT use power tools to assemble the blades. If screws are overtightened, blades may crack and break. motor housing Time Saver: Washers for blade screws can be set on each blade screw prior to installing blades.
Page 9: Light Kit Assembly
10. Light Kit Assembly (Optional). motor housing If you wish to use the light kit, remove all 3 screws on outer edge of switch housing cap on top of light kit. Connect WHITE wire from motor housing to molex WHITE wire from light kit. Connect BLACK wire connections switch from motor housing to BLACK wire from light kit.
Page 10: Testing Your Fan
11. Remote Control Operation. (cont.) Restore electrical power. Within 30 seconds of restoring the power, press and hold the "O" button on the remote control transmitter for 5 seconds or until light on fan blinks twice. Test the light and fan functions to confirm the learning process is complete. NOTE: Remove protective covering from front of remote control transmitter and discard.
Page 11: Troubleshooting
Troubleshooting. Warranty. WARNING: Failure to disconnect power supply prior LIFETIME LIMITED WARRANTY: to troubleshooting any wiring issues may result in The manufacturer warrants this fan to the original serious injury. purchaser for indoor use under the following provisions: 1-YEAR WARRANTY: The manufacturer will replace or repair Problem: Fan fails to operate.
