1. Do not use the compression fitting of the valve to support the valve piping.
The piping may be disconnected from the valve. Be sure to mount the valve to the fixed piping.
(The compression fitting does not have a function to secure and hold the valve.)
Tightening torque
Size
N·m
3/4(20A)
1(25A)
1･1/2(40A)
2(50A)
120
30
50
50
1･1/2(40A)
①
②
-7-
Additional
Size
tightening
angle
3/4(20A)
90° to 270°
1(25A)
135° to 315°
15° to 330°
