Summary of Contents for C.T.M. HS-539
- Page 1 C.T.M. MOBILITY SCOOTER C.T.M. MOBILITY SCOOTER C.T.M. MOBILITY SCOOTER HS-539 Instruction Booklet...
-
Page 2: Table Of Contents
HS-539 Instruction Booklet TABLE OF CONTENTS Introduction --------------------------------------------------------------1 Important Precautions -------------------------------------------------2 Electromagnetic Interference and Warnings ----------------------3 Identification of Parts --------------------------------------------------6 Operating Your Scooter ---------------------------------------------10 ---------------------------------------12 Disassembling Your Scooter Re-assembling Your Scooter ---------------------------------------15 Charging the Batteries ----------------------------------------------16 Care and Maintenance ----------------------------------------------18... -
Page 3: Introduction
HS-539 Instruction Booklet INTRODUCTION Thank you and congratulations on purchasing your new C.T.M. Mobility Scooter. It is designed to provide you with transportation indoors and outdoors. Chien Ti Enterprise Co., Ltd. is the manufacturer for the C.T.M. mobility scooter. We pride ourselves on providing safe and comfortable products. -
Page 4: Important Precautions
HS-539 Instruction Booklet IMPORTANT PRECAUTIONS •Only one person at a time could ride a C.T.M. Mobility Scooter. •Maximum load is 135 kg / 300 lbs. •Turn key off before getting on or off. •Always drive carefully and be aware of others using the same area. -
Page 5: Electromagnetic Interference And Warnings
HS-539 Instruction Booklet ELECTROMAGNETIC INTERFERENCE AND WARNINGS CAUTION: It is very important that you read this information regarding the possible effects of Electromagnetic Interference on your motorized scooter. Powered wheelchairs and motorized scooters may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios, and cellular phones. - Page 6 HS-539 Instruction Booklet 3.Long-range transmitters and transceivers such as commercial broadcast transmitters (radio and TV broadcast antenna towers) and amateur (HAM) radios. Other types of hand-held devices, such as cordless phones, laptop computers, AM/FM radios, TV sets, CD players, and cassette players,...
- Page 7 HS-539 Instruction Booklet 4.Be aware that adding accessories or components, or modifying the motorized scooter, may make it more susceptible to EMI; and. There is no easy way to evaluate their effect on the overall immunity of the motorized scooter.
-
Page 8: Identification Of Parts
Throttle Control Lever Tiller Angle Adjustment Tilting Armrest Front Basket Seat Rotation Lever Optical Headlights Side Reflectors Seat Sliding Lever Figure 1 - HS-539 Front View Self-Diagnostic Warning Light Speed Control Knob Hazard Light Button Storage Cover Armrest Width Horn... - Page 9 HS-539 Instruction Booklet Function Of Parts： •MAIN SWITCH (A) (See Fig. 4) 1.Turn the key clockwise to ON to switch power on status. 2.Turn the key counterclockwise to OFF to switch power off status. •SPEED CONTROL KNOB (B) (See Fig. 5) 1.Turn the speed control knob clockwise for faster speed.
- Page 10 HS-539 Instruction Booklet •ARMREST ADJUSTMENT (See Fig. 8) 1.Release Thumbscrew (E), to adjust the armrest's width; tighten to lock in the comfortable desired position. •ARM PAD ADJUSTMENT (See Fig. 9) 1.Adjust the handrail bolt's (F) height, to control the armrest's horizontal angle.
- Page 11 HS-539 Instruction Booklet •CIRCUIT BREAKER (See Fig. 12) 1.If the scooter's circuit system malfunction or over loaded, the circuit breaker (K) will automatically switch off the power to ensure safety. 2.After automatically power switch off by press the circuit breaker can be reset.
-
Page 12: Operating Your Scooter
HS-539 Instruction Booklet OPERATING YOUR SCOOTER Before beginning your journey with your new scooter, make sure that the scooter is on a level surface and clear of any obstacles. Although your scooter is able to climb slopes it is safer to practice on a leveled surface. - Page 13 HS-539 Instruction Booklet Keep in mind these rules： •Release the Throttle and allow the scooter to stop completely before changing from forward to reverse, or reverse to forward. •When turning a corner, swing the front wheels wide, because the back wheels will turn more tightly.
-
Page 14: Disassembling Your Scooter
HS-539 Instruction Booklet DISASSEMBLING YOUR SCOOTER Taking apart your scooter enables you to save space when keeping it in storage or to carry it along in your vehicle when going away from home. Having the scooter disassembled is easier than ever since no tools are required. Please follow these steps Remove the seat by pull the Seat Rotation Lever (N) up and then lift off. - Page 15 HS-539 Instruction Booklet Detach the Main Wiring Harnesse (R) from the scooter. (See Fig. 21) Unstrap the Velcro Band (S) that holds the batteries. (See Fig. 22) Figure 21 Figure 22 Unplug both Battery Cables (T) and remove the Batteries (U).(See Fig. 23 & 24)
- Page 16 HS-539 Instruction Booklet Push down the Tiller Angle Adjustment (Y) to fold the tiller in a lower position. (See Fig. 27) Once all the parts have been disassembled, you are now able to put the pieces in storage or in a vehicle for transportation. (See Fig. 28)
-
Page 17: Re-Assembling Your Scooter
HS-539 Instruction Booklet RE-ASSEMBLING YOUR SCOOTER To assemble the scooter, you can repeat the disassembly directions in reverse. Abbreviated directions are given below. Refer to the figures on pages 12-13 to locate the parts. 1.Using the tiller angle adjustment, unfold the tiller in an upright position. Place the front basket on the tiller. -
Page 18: Charging The Batteries
HS-539 Instruction Booklet CHARGING THE BATTERIES Batteries must be charged before using the scooter for the first time and should be recharged after each day use. You will need the scooter and the battery charger. Each country may supply different charger. - Page 19 HS-539 Instruction Booklet The time needed to recharge will vary depending on the depletion of the batteries. Charging for longer than necessary will not harm the batteries. They cannot be overcharged. Keep in mind these rules： •Fully charge batteries at least once a month, more if you use the scooter regularly.
-
Page 20: Care And Maintenance
HS-539 Instruction Booklet CARE AND MAINTENANCE Taking care of your scooter will keep it in top-notch condition. It is recommended that you have your dealer to provide preventative maintenance service of your scooter on a regularly basis. Here are a few maintenance guidelines: BODY COVER: If your scooter is dirty, use a damp or lightly soapy cloth to wipe it down. -
Page 21: Troubleshooting
HS-539 Instruction Booklet TROUBLESHOOTING To check the Self-Diagnostic Warning Light, turn on the key and count the number of flashes. Impact Flash Code/Fault Notes on Scooter 1. Battery needs Battery charge is running Iow. Will drive recharging Recharge the batteries as soon as possible. - Page 22 HS-539 Instruction Booklet Other Problems： •Scooter will not move when the key is turned on: 1.Check the power reserve indicator on the control panel. All the LED lights should be on. 2.Check the Self-Diagnostic Warning Light. It should be steady. If it is flashing, see chart on page 18 for problem identification.
-
Page 23: Technical Specifications
HS-539 Instruction Booklet SPECIFICATION Overall Length 1210 mm / 47.6" Overall Width 625 mm / 24.6" Overall Height 1160 mm / 45.6" Front Wheels 290 mm / 11" Rear Wheels 290 mm / 11" Weight W/ Batteries 93.48 kg / 206 lbs Max.
