Dimension - RGBlink mini-mx Quick Start Manual

7 Locking Hole
8 Power Socket
9 Power Switch
10 3.5mm mini-Jack
6.35mm TRS Jack
11
(AUDIO OUT)
12 LINE IN
13 MIC IN 2
14 MIC IN 1
15 +48V Dip Switch

Dimension

Following is the dimension of mini-mx for your reference:
280mm × 222.6mm × 63.5mm.
mini-mx
●Can be used with T-lock to fix the device.
●PD 12V, 3A USB-C power input.
●Rocker switch to power on or off your device.
●Audio Jack for PREVIEW or PROGRAM monitoring.
●Balanced 6.35mm XLR Jack.
●Balanced 6.35mm XLR Jack to connect to mobile
phone, computer or audio console.
●XLR/TRS NEUTRIK MIC IN Port.
●XLR/TRS NEUTRIK MIC IN Port with 48V Phantom
Power supported.
●48V Phantom Power supported.
●Defaults to OFF.
Quick Start 8
