RGBlink mini-mx Quick Start Manual page 8

No. Name
1 UVC (WEBCAM)
2 USB-C
3 LAN
HDMI-A
4
(PROGRAM)
HDMI-A
5
(MULTI-VIEW)
6 1-4 HDMI IN
mini-mx
11
10
Description
●Audio and video stream output port.
●Connect mini-mx to a laptop for instant recognition
as webcam for streaming or video conference.
●Use with USB-C cable provided to share network with
mobile phone.
● Insert SSD or U disk to USB 3.0 recording output
interface for recording.
●Insert a U disk to import audio, video and pictures.
●Gigabit network port for web streaming, PTZ control
and firmware upgrade.
●PROGRAM output port. Multi-view, Program, Test
Pattern optional.
●Multi-view output port. Multi-view, Program, HDMI
1-4 optional.
●1-4 HDMI inputs to connect HDMI video sources, up
to 4K resolution and downward compatible with all
resolution.
Quick Start
12 13 14 15
7
