SIIG CE-HM0031 Quick Installation Manual

Dvi + audio to hdmi

Advertisement

Quick Links

Introducing the DVI + Audio to HDMI
The DVI + Audio to HDMI provides a low cost solution for
converting DVI video plus either digital audio or analog
stereo audio to Digital HDMI.

Features and Benefits

Allows DVI based devices such as PCs with S/PDIF
or analog stereo to be connected to HDMI enabled
TVs
Fully HDCP compliant
Supports DVI video up to 165MHz
Features Coaxial S/PDIF and stereo audio inputs

Technical Specifications

Video Amplifier bandwidth: 1.65Gbps
Video signal output: 1.2V (peak to peak)
Output DDC signal: 5V (peak to peak) TTL
Single link range: 1080p/1920 x 1200
HDMI connector: 19 pin female
DVI connector: DVI-I 29-pin female (digital only)
Power consumption: 10 watts (max)

Package Contents

DVI + Audio to HDMI
Power adapter (5V, 2A)

Quick Installation Guide

04-0496A
DVI + Audio to HDMI
Quick Installation Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CE-HM0031 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SIIG CE-HM0031

  • Page 1: Quick Installation Guide

    DVI + Audio to HDMI Quick Installation Guide Introducing the DVI + Audio to HDMI The DVI + Audio to HDMI provides a low cost solution for converting DVI video plus either digital audio or analog stereo audio to Digital HDMI. Features and Benefits •...
  • Page 2: Front Panel

    Front Panel S/PDIF In Rear Panel Status HDMI Indicator Rotary Switch Modes • 0: Analog mode • 1: S/PDIF audio mode • 2-5: Reserved • 6: EDID default • 7: EDID update from HDMI port. To enable image, set rotary switch to 7, when image appears return to Status Indicator Green indicates a good connection.
  • Page 3: Hardware Installation

    Hardware Installation Connect your DVI source to the DVI In of the DVI + Audio to HDMI. Connect either your digital S/PDIF or stereo audio source to S/PDIF In or Stereo Audio In, respectively, of the DVI + Audio to HDMI. Connect your HDMI TV or other HDMI enabled display to HDMI Out of the DVI + Audio to HDMI.
  • Page 4 FAQs • Only HDMI enabled TVs with underscan/overscan* support can accurately display full active video. Some HDMI equipped TVs cannot support this feature. If underscan/overscan is not supported, the top, bottom, left and right border of the active video may be distorted, and the S/PDIF audio may not sound right.
  • Page 5 Blank Page...
  • Page 6 Blank Page...
  • Page 7 Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA. If the product is determined to be defective, an RMA number will be issued. Step 2: After obtaining an RMA number, ship the product.
  • Page 8 Fremont, CA 94538-3152, USA Ph: 510-657-8688 DVI + Audio to HDMI is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Other names used in this publication are for identification only and may be trademarks of their respective companies.
