Introduction

The DisplayPort 1.2 to 3-Port HDMI MST Splitter boosts
your productivity by allowing you to connect three HDMI
displays to your DisplayPort Multi-Stream Transport
(MST) enabled computer.

Key Features and Benefits

• Capable of multiple display modes for various
Applications. Mirror mode, Extended mode with
individual content on each display, and panoramic
video wall mode which combines multiple monitors
into one large display
• Supports UHD video resolutions up to 3840x2160
(4Kx2K) and 7.1-ch surround audio
• Compatible with DisplayPort 1.2 graphics cards with
AMD Eyefinity or NVIDIA Surround technology
• Plug-n-play, hassle-free set up - no software or driver
installation needed
• Premium aluminum housing delivers efficient heat
dissipation for dependable performance and superior
electro-magnetic shielding for optimal viewing quality
04-1075A
DisplayPort 1.2 to 3-Port
HDMI MST Splitter
User Reference Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CE-DP0C12-S1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SIIG CE-DP0C12-S1

  • Page 1 DisplayPort 1.2 to 3-Port HDMI MST Splitter User Reference Guide Introduction The DisplayPort 1.2 to 3-Port HDMI MST Splitter boosts your productivity by allowing you to connect three HDMI displays to your DisplayPort Multi-Stream Transport (MST) enabled computer. Key Features and Benefits •...
  • Page 2 Specifications Chipset STDP4320 Compliance DisplayPort 1.2a Output signal HDMI Maximum resolution 3840x2160 @30Hz Audio 7.1-ch surround audio Mirror, Extended, and Panoramic video wall Display mode mode Input: 1x 20-pin, DisplayPort, Male Connectors Output: 3x 19-pin, HDMI , Female Power: Micro-USB, Female Housing material Aluminum Built-in cable length...
  • Page 3 Layout Micro-USB power port HDMI Output (x3) DisplayPort In Figure 1: DisplayPort 1.2 to 3-Port HDMI MST Splitter • DisplayPort In: Connect to PC's DisplayPort • HDMI Output (x3): Connect to HDMI displays with HDMI cables (not included) • Micro-USB power port* (no data transfer): Connect to a USB port using the included Micro-USB power cable *Note: This connection is required to power the...
  • Page 4 Hardware Installation Important: If the source's DisplayPort signal doesn't support DP 1.2, the Multiple Stream Transport function will be disabled and this adapter becomes a splitter, mirroring your video source across all displays. 1. Power off all devices you plan to connect to the unit. 2.
  • Page 5 Monitors & Resolutions Support The total bandwidth of 21.6 Gbps is shared amongst all attached monitors. If the total bandwidth is consumed by the first and second HDMI monitors, the remaining monitor will be disabled (no video output). Please refer to the table below: Monitor 1 Monitor 2 Monitor 3...
  • Page 6 For AMD Eyefinity Video Cards Go to AMD Radeon Settings, and click Eyefinity for advanced display mode setup such as video wall. Refer to your graphic card menu for more details. Figure 3...
  • Page 7 Go to www.siig.com, click Support, then REQUEST A PRODUCT REPLACEMENT to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request will be processed, if the product is determined to be defective, an RMA number will be issued.
  • Page 8 Fremont, CA 94538-3152, USA Phone: 510-657-8688 DisplayPort 1.2 to 3-Port HDMI MST Splitter is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. All other names used in this publication are for identification only and may be trademarks of their respective owners.
