Assembly and Operating Instructions for Outback®
Drawings are not to scale.
Specifications subject to change
without prior notice.
•
For outdoor use only. Not for commercial use.
•
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
•
Warning: accessible parts may be very hot. Keep young children and pets away.
•
Do not move the appliance during use.
•
Turn off the gas supply at the gas bottle after use.
•
Any modification of the appliance, misuse, or failure to follow the instructions may
be dangerous and will invalidate your warranty. This does not affect your statutory
WARNING
rights.
•
Retain these instructions for future reference.
•
Leak test annually, and whenever the gas bottle is removed or replaced. Check that
the hose connections are tight and leak test each time you reconnect the gas bottle.
•
For Flare-up control please refer to the 'OPERATION' section of this manual.
FOR YOUR SAFETY
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
Party 6 Burner Gas BBQ
FS5680
1.
2.
FOR YOUR SAFETY
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
A gas bottle not connected for use must not be
stored in the vicinity of this or any other
appliance.
0359

Advertisement

Table of Contents
loading

Related Manuals for Outback Party FS5680

Summary of Contents for Outback Party FS5680

  • Page 1 Assembly and Operating Instructions for Outback® Party 6 Burner Gas BBQ FS5680 Drawings are not to scale. Specifications subject to change 0359 without prior notice. • For outdoor use only. Not for commercial use. • Read instructions before using the appliance. Failure to follow instructions could result in death, serious bodily injury, and/or property loss.

  • Page 2: Parts List

    Parts List Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’. Outback® Party 6 Burner CODE PART Gas BBQ Barbecue Body Burner Control Panel...

  • Page 3: Parts Diagram

    Parts Diagram Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
  • Page 4 Hardware Reference Diagram Specifications subject to change without prior notice. M6x12 Bolt M6 Wing Bolt...
  • Page 5 Assembly IMPORTANT! TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver, • adjustable spanner or metric spanner set. Remove any internal component or packaging from the barbecue body. • Whilst every care is taken in the manufacture of this product, care must be taken during assembly in •...
  • Page 6 Carefully turn the trolley assembly over right side-up. Unfold the trolley assembly as shown. Attach one Side Shelf Support (C1) to the barbecue body using M6x12 Bolts (D1x6pcs) as shown. Repeat above process for the other side shelf support. Make sure the side shelf buffers face upward when attaching the side shelf support.
  • Page 7 Carefully place the barbecue body assembly onto the trolley assembly, and fix with M6 Wing Bolts (D2x2pcs). Then lock the four latches as shown. Unlock the latch on the side shelves, and extend them to horizontal position. Unfold the Wind Shields (B11, B12, B13) and secure them in position by in placing the locking tabs on side wind shields into the slots in barbecue body.
  • Page 8 Remove the plastic wrap from the Lava Rock (B6) and then distribute the Lava Rock evenly in the Basket (B7). Lay the lava rock carefully into the body ensuring it lies level within the body. Lay the Cooking Grill (B8) and Griddle (B9) into place. NOTE: Ensure that the lava rock lies directly underneath the grills.
  • Page 9 (Left view of the barbecue trolley) Attach the Screen (C6) to the front left/right legs as shown. Connect the Hose and Regulator Assembly (B10) to the barbecue. Ensure the mating faces of the connection are clean and not damaged. Do not use any sealing tape, paste, or liquid on the connection.

  • Page 10: Leak Testing

    Leak Test Diagram 1. Maximum diameter or breadth is 320mm. 2. Maximum height (regulator included) is 700mm. ASSEMBLY IS NOW COMPLETE. PROCEED TO THE NEXT PAGE FOR INSTRUCTIONS ON OPERATION AND MAINTENANCE ALL JOINTS AND CONNECTIONS MUST NOW BE LEAK TESTED BEFORE USING THE BARBECUE.

  • Page 11: Gas, Regulator And Hose

    Important Information Before you use your barbecue, perform a leak test. This is the only safe and sure way Please read these instructions carefully to detect any gas leaking from joints and before assembly and use of your barbecue. connections of the barbecue after assembly. Leak test annually, and whenever the gas Retain these...

  • Page 12: Installation

    INCORRECT OR FAULTY REGULATOR IS understand IMPORTANT DANGEROUS AND WILL INVALIDATE ANY INFORMATION section of this manual. WARRANTY. Please consult your local gas Your barbecue is not designed to be used dealer for the most suitable gas bottles and with more than 50% of the cooking area as a regulators.
  • Page 13 Manual Ignition Instructions Smoke of course helps give food its barbecued • Open the barbecue hood or lid before flavour, but it is best to avoid excessive flare-up to prevent food being burned. To control flare- lighting. Never light your barbecue with the ups, it is ABSOLUTELY ESSENTIAL to trim hood or lid closed.

  • Page 14: Care And Maintenance

    sure the hood or lid is open during this process. and dry thoroughly. Due to the weight of the cooking surfaces, we do not recommend cleaning in a dishwasher. Turning Off Your Barbecue When you have finished using your barbecue, It is quite normal for surface rust to be present turn all the control valves fully clockwise to the on the cooking surface.
  • Page 15 barbecue body using a cloth wrung out in hot soapy water and dry thoroughly. Excess fat and food debris can be removed from inside the body using a soft plastic or wooden scraper. It is not necessary to remove all the grease from the body.

  • Page 16: Technical Specifications

    Technical Specifications NOTES: Heat Injecto Burners Gas /Pressure Approval Input r Size Outback® Party 6 0359 17.28 0.84m Butane: 28-30 mbar Burner Gas Propane: 37 mbar 359BR665 Gas Consumption: 1258g/hr Countries of Use: BE, CH, CY, CZ, ES, FR, GB, GR, IE, IT, LT, LU, LV, PT, SK, 3+ (28-30/37) Specifications subject to change without prior notice.

  • Page 17: Troubleshooting

    Troubleshooting Problem Possible Cause Solution Burner will not light using LP gas bottle is empty Replace with full bottle the ignition system Faulty regulator Have regulator checked or replaced Obstructions in burner Clean burner Obstructions in gas jets or gas hose Clean jets and gas hose Electrode or ignition button wire is loose Reconnect wire...
  • Page 18 OUTBACK® WARRANTY OUTBACK® barbecues are warranted to the original purchaser against defects in materials and workmanship. OUTBACK® will supply replacements for defective parts free of charge provided that: The product has not been used for trade, professional or hire purposes.
