Rayleigh Instruments RI-ENERGYFLOW-3P-MODULAR RI-ENERGYFLOW-HYBRID User Manual page 49

Menu Menu Menu
Level 1 Level 2 Level 3
Grid
STD
Menu Menu Menu Level
Level 4 Level 5
Enable
Time Set time
Automatic
Heating
ON
FLIM
OFF
Disable
BMS
DOD
Enable
Disable
Maintain
SOC
Enable
Disable
Force
Wake
Enable
1.China
2. Germany
AUS-A
3.
AUS-B
Australia
AUS-C
CEI0-21
4. Italy
CEI0-21 ACEA
49
Default
6
Selection
up and check the state of
charge and depth of
discharge at the interval set.
If time is selected the user
will be prompted to enter a
value 0...300 minutes.
Allows the user to enable or
disable the heating film
installed within the battery
modules. Automatic means
the system measures the
Automatic
Outside temperature and
turns the film on as needed.
Only applicable if heating film
is requested at time of
ordering.
Leave disabled. The inverter
Disable will monitor depth of
discharge.
Disable: The minimum SOC
will not be maintained.
Enable: The minimum SOC
2% is maintained. When the
Enable
battery SOC is less than 2%,
the grid charges the battery
pack to 5% through the
inverter.
Enabling this option means
the battery will always remain
Disable
online and will not go to
sleep.
Allows the user to select the
Local country that the system is
installed in.
Comment
