2.2

Installing the mSATA

Step 1

Turn off the system.

Step 2

Loosen all the screws of the cover and remove the cover from the system.

Insert the mSATA into the slot which marking with "mSATA / USB / PCIe".

Step 3

Hardware Installation

ICO120-E Series User's Manual
