Thank you for purchasing this Takara Belmont product.
Be sure to read this operation manual before operating the chair and always operate
the chair properly according to the instructions herein.
Failure to read this operation manual may lead to accidents.
●Carefully store this operation manual in a secure location near this product where
they can be readily accessed, and refer to them whenever necessary.
●This product is a barber chair designed for the services offered at hair salons.
Do not use this product for any purposes other than those described above.
This product shall be operated only by qualified hairdressers.
●Ask your authorized Takara Belmont dealer to install this product.
Please contact Takara Belmont with the BOOK No. (outlined below) if this operation
manual becomes torn or damaged and unreadable, or is lost.
Takara Belmont Barber Chair
Model No.
Operation Manual
AB-DVZF
2023- 04 (1s t edi t ion)
BOOK No.1E09JXAE
BOOK No.1E09JXAE
Advertisement
Table of Contents
Related Manuals for Takara Belmont DIVAN-Z AB-DVZF
Summary of Contents for Takara Belmont DIVAN-Z AB-DVZF
- Page 1 This product shall be operated only by qualified hairdressers. ●Ask your authorized Takara Belmont dealer to install this product. Please contact Takara Belmont with the BOOK No. (outlined below) if this operation manual becomes torn or damaged and unreadable, or is lost.
-
Page 2: Table Of Contents
C o n t e n t s Introduction Explanation of Warning Labels ................. 3 Safety Precautions ................... 4 Use Precautions ....................9 Precautions Related to Synthetic Leather ............11 Locations of Warning Labels ................11 Accessories ....................11 Part Names ....................12 Preparation Turn on power .................... -
Page 3: Explanation Of Warning Labels
To ensure safety, adhere to these precautions at all times. Takara Belmont has absolutely no responsibility for accidents that might be caused by failure to obey "Safety Precautions" and "Use Precautions" resulting in injury to users and other persons, or other damage. -
Page 4: Safety Precautions
Installation/Transport Installation precautions • Ask your authorized Takara Belmont dealer to install this product. • The chair must be installed on a perfectly flat and solid floor. Installing the chair to a non-flat floor can result in the chair tipping over. - Page 5 Safety Precautions WARNING Use and Cleaning Precautions Be careful to keep hands, fingers and other body parts of the customer and user from touching or getting close to moving parts. Doing so may cause the unit to have them pinched, resulting in injury. Customer must not lie on his/her stomach, put his/her legs or feet on the seat, or sit on the product with a child in his/her arms.
- Page 6 Safety Precautions WARNING Use and Cleaning Precautions Precautions when getting in and out of the chair • When the customer gets on or off the chair, the chair should always be at entry/exit position (auto return position) with the chair rotation locked. •...
- Page 7 • If the connection becomes loose, immediately stop using the equipment attached to the service outlet and unplug the equipment from the service outlet. Contact your authorized Takara Belmont dealer as soon as possible for inspection or replacement parts.
- Page 8 If you feel that something seems slightly different or not normal, immediately stop using the chair, turn off the power and unplug the power plug, and contact your authorized Takara Belmont dealer. Always be sure to use your hands to operate the switches.
-
Page 9: Use Precautions
Do not use outdoors. Doing so can result in damage. Contact your authorized Takara Belmont dealer if the breaker function (p. 34) frequently operates. Maximum load (maximum lifting capacity) is 135kg. The lifting speed of the chair may change or the operation noise may increase depending on the weight of... - Page 10 Use Precautions Operate the fan once a month Even if the fan is not used for a long period of time, operate the fan once a month. If dust or hair accumulates inside the fan, dust or hair may come out when the fan is running, or the fan itself may cause malfunction.
-
Page 11: Precautions Related To Synthetic Leather
Precautions Related to Synthetic Leather Clothing dye adhering The color of clothing or belts can be transferred to the synthetic leather of this chair by means of contact. If color adheres to the leather, wipe off the stain as soon as possible before it soaks in by using a soft cloth that has been dabbed with a neutral detergent diluted with water to approximately one tenth, wipe it with a damp cloth and thoroughly wipe it dry. -
Page 12: Part Names
Part Names Main Unit Headrest (With headrest cover) (p. 16) Fan (p. 29) Backrest Armrest (with retractable table) (p. 30) Control panel (Left) Seat (p. 13) Cape holder (p. 25) Legrest Body (Left) Footrest (Removable) (p. 32) Attach the provided protective sticker (for preventing Foot cushion Footrest pad scratches) to the armrest and fold-out table before use. - Page 13 Part Names Control Panels Left Right ④ ⑤ ⑥ ⑦ ⑧ ⑩ ⑦ ⑨ ⑥ ⑤ ④ ① ① ② ② ③ ⑧ ① Preset switch P1 ⑦ Auto-return switch ② Preset switch P2 ⑧ Service outlet ③ Preset switch P3 ⑨...
-
Page 14: Turn On Power
Turning on power Inserting the power plug into the outlet Power plug Outlet (With ground terminal) Power cord Correctly insert the power plug into an outlet with a ground terminal. Ground • Use an unshared outlet that has an attached ground terminal and matches the rated voltage and current *of this product. -
Page 15: Rotating The Chair
Rotating the chair Foot control Rotation lock switch Backrest Body Hold the backrest or body when rotating the chair. (You can rotate the chair a full 360°.) When the rotation is locked, stepping on the rotation lock switch to unlock it. Each stepping of the rotation lock switch alternately locks and unlock the rotation. -
Page 16: Adjusting The Headrest
Adjusting the headrest Use the headrest when supporting the customer's head is needed, such as for shaving. Tip the headrest forward to fit it against the customer's head so that the customer will be more comfortable even if used for an extended period. 1. - Page 17 Adjusting the headrest Detaching/Attaching the headrest If you do not use the headrest, you can remove it by Headrest support frame pulling it out. When attaching, insert the hole of the headrest support frame into the lock support bar while press- ing the headrest operation lever, aligning the guide.
-
Page 18: Raising/Lowering The Chair
Raising/Lowering the Chair Control panel (Left) Control panel (Right) UP/DOWN switch UP/DOWN switch Foot control UP/DOWN switch (Down) UP/DOWN switch (Up) The chair moves up and down while a switch is pressed. ⇒Even if the chair is unlocked, rotation mechanism will be locked before the chair is activated. To fine-adjust the position When lowering the chair, the position can be finely adjusted by pressing the switch little by little. -
Page 19: Reclining/Raising The Backrest
Reclining/Raising the Backrest Control panel (Left) Control panel (Right) Backrest switch Backrest switch The backrest will recline/raise while the switch is held down. ⇒Even if the chair is unlocked, rotation mechanism will be locked before the chair is activated. To fine-adjust the position When reclining the backrest, the position can be finely adjusted by pressing the switch little by little. -
Page 20: Raising/Lowering The Legrest
Raising/Lowering the Legrest Control panel (Left) Control panel (Right) Legrest switch Legrest switch The legrest moves up and down while the switch is pressed. The footrest is also moved up and down in conjunction. ⇒Even if the chair is unlocked, rotation mechanism will be locked before the chair is activated. To fine-adjust the position When lowering the legrest, the position can be finely adjusted by pressing the switch little by little. -
Page 21: Moving The Chair To Preset Positions
Moving the Chair to Preset Positions Using the preset function Preset Function Pressing the switch just once moves the chair to a preset position. You can set up to three optional positions of this chair. Control panel (Left) Control panel (Right) Preset switches (P1 to P3) Preset switches (P1, P2) Press either switch. - Page 22 Moving the Chair to Preset Positions Using the auto-return function Control panel (Left) Control panel (Right) Auto-return switch Auto-return switch Blinks during operation. Blinks during operation. The chair, backrest, and legrest return to entry/exit position. Footrest also lowers in conjunction. (The "RETURN"...
- Page 23 Moving the Chair to Preset Positions Adjusting preset positions Although the setting positions of the preset switches are previously set, you can change to the positions to match your needs and preferences. Set the positions of the preset function with a person sitting in the chair. The chair is equipped with a shockless device.
- Page 24 Moving the Chair to Preset Positions Setting the fit mode What is Fit Mode... This product is equipped with a shockless device, which will cause slight variance in the stop position. Use this setting when you want to adjust the height to the bowl properly, such as when back shampooing. 1.
-
Page 25: Using The Cape Holder
Using the Cape Holder Using the cape holder: • Provides space between the customer and the cutting cape to provide good ventilation. • Makes it easy to clean up the cut off hair. 1. Rotate the cape holder forward. 2. Pull out the tip of the cape holder and pinch the cutting cape between the parts. ①Pull from the top of the cutting cape ②Pinch the cutting cape and release 3. -
Page 26: Using The Dryer/Iron Holder
Using the Dryer/Iron holder Pull out the dryer/iron holder located on the right side. Use it when hanging a hand dryer / iron temporarily. Dryer holder Iron holder Dryer / Iron holder • Store the dryer/iron holder when not in use. •... -
Page 27: Using The Service Outlets
• If the connection becomes loose, immediately stop using the equipment attached to the service outlet and unplug the equipment from the service outlet. Contact your authorized Takara Belmont dealer as soon as possible for inspection or replacement parts. • Remove the power plug of a device from the service outlet when not using it. -
Page 28: About Shockless Move
WARNING Should red spots or blister occur, immediately take the diagnosis of a medical specialist. • If you notice abnormal heat when using the heater, turn off the power switch, unplug the equipment, and contact your authorized Takara Belmont dealer. -
Page 29: Using Fans
Using Fans This product can operate fans inside the armrest at customer's request. Push the fan switch to LOW. The fan will produce soft air flow (Fan switch lights up in green). Push the fan switch to HIGH. The fan will produce strong air flow (Fan switch lights up in green). The fan will not operate when the backrest is reclining over 120°(because the body is lowered and the fan outlet is covered). -
Page 30: Using The Fold-Out Table
Using the fold-out table Attach the provided protective sticker (for preventing scratches) to the armrest and fold-out table before use. (Refer to the separate sheet "DIVAN-Z Attaching the provided protective stickers") 1. Pull out the table straight up, holding the armrest (sitting right) with both hands until the end. -
Page 31: Using The Foot Cushion (Optional)
Using the Foot Cushion (Optional) This chair has a foot cushion that can be placed on the footrest on which the customer's legs can rest in order for the customer to recline with comfort. Place the foot cushion with the zipper side down. Legrest Foot cushion Footrest... -
Page 32: Removing The Footrest
Removing the Footrest You can remove the footrest anytime it might interfere such as when sitting a wheelchair customer in the chair or using a foot spa machine. Attaching/detaching the footrest Detaching the footrest Pull up the footrest at an angle with both hands and pull it up towards you to remove it. Footrest Attaching the footrest ①Insert the footrest bracket into the hole of the footrest mount. -
Page 33: Cleaning Procedures
Cleaning Procedures Clean this chair after use to maintain it in a clean state. Leaving dirt or grime on the chair can result in the formation of mold. • Turn off the power switch and unplug the power plug before cleaning. Failure to do so can result in electric shock or fire. -
Page 34: Troubleshooting
If any of the problems described below occur, conduct the checks outlined before requesting repair. If the chair does not work normally even after performing the recovery procedures, immediately stop using the chair, turn off the power, unplug the power plug, and contact your authorized Takara Belmont dealer. Problem... -
Page 35: Daily Inspection
If the alarm still than that for the warm-up mode (p. 28). sounds, contact your authorized Takara Belmont dealer. Check that there is no rattling or If there is any abnormality, contact your authorized abnormal noise when operating the chair. -
Page 36: Standard Period Of Use
The length of the "standard period" differs depending on the use environment and frequency of use of the customer. For maintenance after the standard period of use, contact your authorized Takara Belmont dealer. Disposing of this Product Dispose of this chair and replaced parts in a proper manner that complies with local laws and regulations. -
Page 37: Specifications
Specifications Model no. ……………………… AB-DVZF Weight…………………………… 155kg Seat ……………………………… Electrohydraulic system Initial height/stroke …………… 510/280 mm Maximum lifting capacity ……… 135 kg Headrest ………………………… Manual type Backrest ………………………… Electrohydraulic system Legrest…………………………… Electrohydraulic system Upholstered part ………………… Synthetic leather Operating switches ……………… Switches of the base operation part and the operation part Use environment …………………... - Page 38 NOTE...
- Page 39 NOTE...
- Page 40 MANUFACTURER TAKARA BELMONT CORPORATION 2-1-1, Higashishinsaibashi, Chuo-ku,Osaka, 542-0083, Japan TEL : +81-6-6213-5945 / FAX : +81-6-6212-3680...
