Operation
Label/Color
<RED> Button
<AMBER> Button
<YELLOW> Button
<GREEN> Button
<BLUE> Button
<CYAN> Button
<MAG> Button
<WW> Button
<UV> Button
<MOVING HEAD> Button
<PAR> Button
Button Press to activate laser control, to set lasers to default, and to deactivate
<LASER>
<STROBE EFFECT> Button
<DERBY> Button
<COLOR> Button
<MOVEMENT> Button Press to cycle through movement macros for moving heads
<SPEED> Button Press to cycle through speeds for the associated effect
<GOBO> Button
<MACRO> Button
<PATTERN|SPEED> Button Press to cycle through patterns/speeds for lasers
<PATTERN> Button Press to cycle through patterns for strobe effects
<PRESET 1–6> Button
ILS Command User Manual Rev. 1
Type Function
Press to toggle all output to red (color override) and to select RED on the
Color Macro Setting screen
Press to toggle all output to amber (color override), to select AMBER on
the Color Macro Setting screen, and to select a parameter when
programming follow spot mode
Press to toggle all output to yellow (color override) and to select
YELLOW on the Color Macro Setting screen
Press to toggle all output to green (color override), to select GREEN on
the Color Macro Setting screen, and to select a parameter when
programming follow spot mode
Press to toggle all output to blue (color override) and to select BLUE on
the Color Macro Setting screen
Press to toggle all output to cyan (color override), to select CYAN on the
Color Macro Setting screen, and to select a parameter when
programming follow spot mode
Press to toggle all output to magenta (color override) and to select MAG
on the Color Macro Setting screen
Press to toggle all output to warm white (color override), to select WW on
the Color Macro Setting screen, and to select a parameter when
programming follow spot mode
Press to toggle all output to ultraviolet (color override) and to select UV
on the Color Macro Setting screen
Press to activate moving heads, to set moving heads to default, and to
deactivate moving heads
Press to activate par and wash effects, to set par and wash effects to
default, and to deactivate par and wash effects
lasers
Press to activate strobe effects, to set strobe effects to default, and to
deactivate strobe effects
Press to activate derby and kinta effects, to set derby and kinta effects to
default, and to deactivate derby and kinta effects
Press to cycle through colors for the associated effect
For moving heads, press and hold for color scroll
Press to cycle through gobo effects for moving heads, or press and hold
for gobo scroll
Press to activate and cycle through macros for par and wash effects
Press and hold to select up to 4 colors for the macro effect
Press and hold to save shows to the preset slot, then use the <X>
encoder to name the preset and assign a button color
Press to activate and deactivate the preset
