Installation
Wiring (Monitored door)
CAUTION
Make sure that OC-904C T
dipswitch 4 is turned "Enable".
Risk of getting caught
OC-904C T
OA-603 T
OA-603 T
Wiring (Not monitored door)
CAUTION
Make sure that OC-904C T
dipswitch 4 is turned "Disable".
Risk of getting caught
OC-904C T
OA-603 T
OA-603 T
Adjustments
Dipswitch Settings
Safety output
Safety output
hold time
hold time
(0.5 to 10sec.)
Min Max
Safety 1 2
relay contact
Factory setting
1
: 0.5sec N.O. N.C.
Stall
relay contact
2
Operation
N.O. N.C.
indicator
Activation
operation
3
Auto Knowing
Act
Test input
4
Enable Disable
Inform building owner/operator of the following items
1. When turning the power ON, stay clear of detection area for a minimum of 10 seconds then walk test detection area to ensure proper operation.
2. Always keep the detection window clean. If dirty, wipe the window with a damp cloth ( Do not use any cleaner or solvent ).
3. Do not wash the sensor with water.
4. Do not disassemble, rebuild or repair the sensor yourself, otherwise electric shock may occur.
5. Contact your installer or the sales engineer if you want to change the settings.
6. Do not place an object that moves or emits light in the detection area.(ex. Plant, illumination etc..)
7. Do not paint the detection window.
Warning Indication (OC-904C T Controller)
Mode
Operation indicator
The relay is reaching the
Explanation
end of its life cycle.
Contact your installer or the sales engineer if:
- you need to change the settings or replace the sensor.
- the trouble still persists after checking and remedying as described above.
Contact
North and South America Subsidiary
OPTEX INCORPORATED
10741 Walker Rd. Suite 300 Cypress, CA 90630 U.S.A
www.optexamerica.com Tel : +1(800)877 6656
Red/Blue
Gray/Pink
Green
Yellow
Purple
Sensor cable
Black
Red
Brown
Position
sensor
Orange
Red/Blue
Gray/Pink
Green
Yellow
Blue
Purple
Sensor cable
Black
Red
Brown
Position
sensor
Orange
Stall output
hold time
Stall output
hold time
Factory setting
(0.5 to 10sec.)
Min Max
: 0.5sec
3 4 5 6 7 8
Test input
5
High Low
Test input
(Activate output)
6
Enable Disable
Mandatory
7 8
* : Depends on the door operator type,
please set the swtich of test output
(Activate)
Directional plug OC-904C T
Life cycle notification
Twice Green blinking
The sensor cable is connected, but unstable communication.
A sensor cable may be disconnected or OA-603 T mode
switches 7 & 8 may be set wrong. Refer to "Adjustments".
Door controller
Test output (-)
Test output (+)
Stall iuput
Activate iuput
Blue
(Not used)
White/
Purple
line
Activate signal
- +
POWER
Motor
12-24 VAC
12-30 VDC
Activate signal (N.O.only)
Not used
Door controller
Stall iuput
Activate iuput
Safety iuput
White /
Purple
line
Activate signal
-
+
POWER
Motor
12-24 VAC
12-30 VDC
Activate signal (N.O.only)
Communication error
Twice Orange blinking
Manufacturer
OPTEX CO., LTD.
5-8-12, Ogoto, Otsu, Shiga, 520-0101 Japan
2-2
How to use T-tap connector
Time delay module
Electric
Relay1
Door controller
lock
output
motor wire
Knowing act
Activation
devices
input
(i.e.Push plate)
Relay2
delayed
output
Push Plate
OR
Use the T-tap connector unless
PUSH
there are wiring terminals
TO OPEN
Standard optional
ON/OFF/Hold switch
Time delay module
Motion
Electric
Relay1
output lock
sensor
Knowing act
Activation
devices
input
(i.e.Push Plate)
Relay2
delayed
OC-904C T
output
NOTE
Push plate
OR
For Knowing act application, connect
PUSH Purple wire to activate output from
TO OPEN
push button.
Dipswitch setting
1 Safety relay contact
2 Stall relay contact
3 Activation operation
4 Test input
5 Test input
6
Test output (Activate) *
7
Mandatory
8
NOTE
LED will be turned off approx. 500 ms when the
sensor test output signal works well.
Close connector
OC-904C T motor wire
OEM
Door
Hold open
control
OFF
ACT
COM
Auto
ACT
OFF ON
N.O. N.C.
N.O. N.C.
Auto. Knowing act
Enable Disable
High Low
Enable Disable
All "OFF"
