Magtek DynaFlex II Series Installation And Operation Manual page 68

Appendix A - Technical Specifications
Battery Time, Powered Off
Battery Time, Standby:
Battery Time, Transactions:
Voltage Requirements:
Current Requirements:
Data Storage:
Wired Connection Types:
Wireless Connection Types:
Wireless Range:
Wireless Frequencies and
Power:
RF Exposure:
DynaFlex II| Product Family | Installation and Operation Manual
DynaFlex II Products Technical Specifications
Reference Standards and Certifications
4 years or longer
Wireless LAN: Reserved
Bluetooth LE: Reserved
Reserved
5 VDC from USB port
500mA from USB port
Not Applicable
Communication Characteristics
USB-C, compatible with USB 1.1, USB 2.0
Vendor-defined USB Human Interface Device (HID) data format
Bluetooth Low Energy ("Bluetooth LE") (select models)
TCP/IP over Wireless LAN (select models)
WLAN: 100m in a typical environment
Bluetooth LE: TBD
Wireless LAN
Frequency range = 2400 MHz to 2484 MHz
Average power radiated = 0.80 mW (-0.97 dBm)
Bluetooth LE
Frequency range = 2400 MHz to 2480 MHz
Average power radiated = 0.07 mW (-11.55 dBm)
NFC:
Frequency range = 13.56 MHz
Maximum power conducted = 794 mW (29 dBm)
Exempt from SAR requirements due to radiated power substantially
below regulatory thresholds.
Page 68 of 78 (D998200554-10)
