6 - Operation
6.3

About the Status LEDs

DynaFlex II provides four RGB LEDs directly below the chip card insertion slot (see section 1.8 About
DynaFlex II Components), numbered LED1 through LED4, which report the device's current operating
status.
•
The meaning of each LED depends on the device's operating mode. See section 6.1 About Operating
Modes and Table 6-1 below. Most of the time, operators will check the device's status using the
LEDs when it is in Active Mode while the device is not performing a transaction.
•
LED colors have specific meanings, as described in Table 6-2. They are based on international
conventions for traffic light colors, with additional colors reserved for unusual / special cases.
•
LED blinking patterns have specific meanings as well, as described in Table 6-3. A blinking LED
generally means the device is actively doing something to change the state that the LED is indicating
and solid indicates a persistent state that would require an operator or cardholder to take action to
change. One major exception is a device-wide functional failure state, such as a tamper state, where
all LEDs flash urgently to call the attention of an advanced operator to intervene.
In this manual, specific combinations of LED colors and blinking patterns are described in more detail in
the sections where they are relevant and use the same icons in the tables below to indicate color and
blinking patterns. For example, information about how the LEDs show the device's connection status is in
section 4.3 Connecting to a Host.
Table 6-1 – DynaFlex II LED Allocation
In This Context
Active Mode, not armed for
a tap transaction
Active Mode, armed for a
tap transaction
Device-wide failure
DynaFlex II| Product Family | Installation and Operation Manual
LED1 LED2
Power Connection
Armed for Tap Tap Read Progress Tap Read Progress Card Read Result
During major failures (such as tamper), LED1-LED4 report the nature of
the failure based on the most likely steps required to resolve it.
Page 31 of 78 (D998200554-10)
LED3
Reserved Card Read Result
LED4
