UCA-RMK-1U
Rack Mount Kit for UC Engine Bracket Assembly
The Crestron®
UCA-RMK-1U
is a rack mount kit that allows a UC Engine
bracket assembly to be installed into a 19 in. EIA equipment rack.
In the Box
1
Rack Ear, Left (2057927)
1
Rack Ear, Right (2057928)
4
Washer (2007671)
4
Nut (2004887)
Installation
To install the UC Engine bracket assembly into a 19 in. EIA equipment
rack using the rack ears:
1. Place the left and right rack ears on a flat surface.
2. Position the four threaded studs of the left and right rack ears
through the four holes in the UC Engine Bracket Assembly, as shown
in Figure A.
3. Secure the rack ears to the bracket assembly using the included four
washers and four nuts.
Figure A
Quick Start
1
Advertisement
Table of Contents
Related Manuals for Crestron UCA-RMK-1U
Summary of Contents for Crestron UCA-RMK-1U
- Page 1 Quick Start UCA-RMK-1U Rack Mount Kit for UC Engine Bracket Assembly Figure A The Crestron® UCA-RMK-1U is a rack mount kit that allows a UC Engine bracket assembly to be installed into a 19 in. EIA equipment rack. In the Box...
- Page 2 Quick Start UCA-RMK-1U Rack Mount Kit for UC Engine Bracket Assembly 4. Mount the assembled UC Engine Bracket Assembly into the rack using four rack mounting screws (not included), as shown in Figure B. Visit the Product Page Figure B Scan the QR code to visit the product page.
