C5T Series Bullet Camera
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Type I
Camera
Type II
Camera
This manual may contain several technical incorrect
places or printing errors, and the content is subject to
change without notice. The updates will be added to
the new version of this manual. We will readily improve
or update the products or procedures described in the
manual.
TURBO HD
User Manual
Model
DS-2CE16C5T-AIT3Z
DS-2CE16C5T-IT5
0100001081115

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TURBO HD C5T Series and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION TURBO HD C5T Series

Summary of Contents for HIKVISION TURBO HD C5T Series

  • Page 1 TURBO HD C5T Series Bullet Camera User Manual User Manual Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Type Model Type I DS-2CE16C5T-AIT3Z Camera Type II...

  • Page 2: Regulatory Information

    Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.

  • Page 4: Product Features

    1 Introduction 1.1 Product Features The main features are as follows: High performance CMOS sensor  IR cut filter with auto switch  OSD menu with configurable parameters  Auto white balance  SMART IR mode  3-axis adjustment  Wide dynamic range ...

  • Page 5: Installation

    2 Installation Before you start: Make sure that the device in the package is in good  condition and all the assembly parts are included. Make sure that all the related equipment is power-off  during the installation. Check the specification of the products for the ...
  • Page 6 Note: The supplied screw package contains self-tapping  screws, and expansion bolts. For cement wall/ceiling, expansion bolts are  required to fix the camera. For wooden wall/ceiling, self-tapping screws are required. 5. Connect the corresponding power cord, and video cable. 6.
  • Page 7 5. Attach the junction box’s body to the ceiling/wall by aligning the screw holes of the junction box. 6. Secure the junction box’s body with supplied screws on the ceiling/wall. Figure 2-6 Secure the Box’s Body to the Ceiling 7. Route the cables through the cable hole, or the side opening of the junction box.
  • Page 8 Figure 2-9 Install the Camera to the Ceiling Note: The supplied screw package contains self-tapping  screws, and expansion bolts. For cement wall/ceiling, expansion bolts are  required to fix the camera. For wooden wall/ceiling, self-tapping screws are required. 5. Connect the corresponding power cord, and video cable.
  • Page 9 Figure 2-11 Install the Junction Box 6. Route the cables through the bottom cable hole, or the side cable hole of the junction box. 7. Combine the junction box cover with its body with supplied screws on the junction box’s cover. Figure 2-12 Combine the Junction Box’s Cover with its Body 8.

  • Page 10: Menu Description

    3 Menu Description Please follow the steps below to call the menu. Note: Menu description part is only for your reference. It might have some differences due to the specific model that you have. Steps: 1. Connect the camera with the TVI DVR, and the monitor, shown as the figure 3-1.

  • Page 11: Slow Shutter

    5. Click the direction arrow to control the camera. (1) Click up/down direction button to select the item. (2) Click Iris + to confirm the selection. (3) Click left/right direction button to adjust the value of the selected item. 3.2 VIDOE FORMAT You can set the video format as 720P@25fps, or 720P@30fps.
  • Page 12 conditions. You can set the SLOW SHUTTER function as OFF, x2, x4, x6, x8, x10, x12, x14, or x16 according to the different light conditions. 3.4 DAY/NIGHT COLOR, B&W (Black White), and AUTO are selectable for DAY/NIGHT switch. COLOR The image is colored in day mode all the time. B &...

  • Page 13: Video Settings

    You can turn on/off the IR LIGHT to meet the requirements of different circumstances. SMART IR  The Smart IR function is used to adjust the light to its most suitable intensity, and prevent the image from over exposure. You can select the mode as MODE 1, or MODE 2. MODE 1 is the default mode that can be applied to both indoor conditions, and outdoor conditions.
  • Page 14 WHITE BALANCE MANUAL MODE R-GAIN B-GAIN  BACK  EXIT  SAVE & EXIT Figure 3-7 MANUAL MODE BRIGHTNESS Brightness refers to the brightness of the image. You can set the brightness value from 1 to 9 to darken or brighten the image. The higher the value is, the brighter the image is.

  • Page 15: Motion Det

    MOTION DET  Figure 3-8 MOTION Select a MOTION area. Set the MODE as ON. Click the up/down/left/right button to define the position, and the size of the area. Set the SENSITIVITY according to your needs. PRIVACY The privacy mask allows you to cover certain areas which you don’t want to be viewed, or recorded.
