Bullet Camera &Turret
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Type I
Camera
Type II
Camera
This manual may contain several technical incorrect
places or printing errors, and the content is subject to
change without notice. The updates will be added to
the new version of this manual. We will readily improve
or update the products or procedures described in the
manual.
TURBO HD
D8T Series
User Manual
Model
DS-2CE16D8T-(A)IT3ZF
DS-2CE56D8T-IT3ZF
Camera
0100001081023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TURBO HD DS-2CE56D8T-IT3ZF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HIKVISION TURBO HD DS-2CE56D8T-IT3ZF

  • Page 1 ventas@rosarioseguridad.com.ar +54 9 341 6708000 +54 9 341 6799822 Avenida Presidente Perón 3998 - Rosario - Santa Fe - Argentina TURBO HD D8T Series Bullet Camera &Turret Camera User Manual User Manual Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer.
  • Page 2: Regulatory Information

    Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 4 1 Introduction 1.1 Product Features The main features are as follows: High performance CMOS sensor  IR cut filter with auto switch  OSD menu with configurable parameters  Auto white balance  Internal synchronization  SMART IR mode  3-axis adjustment ...
  • Page 5: Installation

    2 Installation Before you start: Make sure that the device in the package is in good  condition and all the assembly parts are included. Make sure that all the related equipment is power-off  during the installation. Check the specification of the products for the ...
  • Page 6 Note: The supplied screw package contains self-tapping  screws, and expansion bolts. For cement wall/ceiling, expansion bolts are  required to fix the camera. For wooden wall/ceiling, self-tapping screws are required. 5. Connect the corresponding power cord, and video cable. 6.
  • Page 7 5. Attach the junction box’s body to the ceiling/wall by aligning the screw holes of the junction box. 6. Secure the junction box’s body with supplied screws on the ceiling/wall. Figure 2-6 Secure the Box’s Body to the Ceiling 7. Route the cables through the cable hole, or the side opening of the junction box.
  • Page 8 3. Loosen screws to remove the clip plate, and take out the main body. Figure 2-9 Remove the Clip Plate 4. Install the camera to the ceiling with supplied screws. Figure 2-10 Install the Mounting Base to the Ceiling Note: The supplied screw package contains self-tapping ...
  • Page 9: Ceiling/Wall Mounting With Junction Box

    1). Hold the camera body and rotate the enclosure to adjust the pan position [0° to 360°]. 2). Move the camera body up and down to adjust the tilt position [0° to 75°]. 3). Rotate the camera body to adjust the rotation position [0°...
  • Page 10 Figure 2-16 Fix the Junction Box 8. Repeat steps 5 to 9 of 2.2.1 Ceiling/Wall Mounting without Junction Box to complete the installation.
  • Page 11: Menu Description

    3 Menu Description Please follow the steps below to call the menu. Steps: 1. Connect the camera with the TVI DVR, and the monitor, shown as the figure 3-1. Figure 3-1 Connection 2. Power on the analog camera, TVI DVR, and the monitor to view the image on the monitor.
  • Page 12: Slow Shutter

    (1) Click up/down direction button to select the item. (2) Click Iris + to confirm the selection. (3) Click left/right direction button to adjust the value of the selected item. 3.1 VIDOE FORMAT When switching the video output as CVBS, you can ...
  • Page 13 frame, which makes a camera more sensitive to the light so it can produce images even in low lux conditions. You can set the SLOW SHUTTER function as OFF, x2, x4, x6, x8, x10, x12, x14, or x16 according to the different light conditions.
  • Page 14: Video Settings

    You can turn on/off the IR LIGHT to meet the requirements of different circumstances. SMART IR  The Smart IR function is used to adjust the light to its most suitable intensity, and prevent the image from over exposure. You can select the mode as MODE 1, or MODE 2. MODE 1 is the default mode that can be applied to both indoor conditions, and outdoor conditions.
  • Page 15: Motion Detection

    WHITE BALANCE MANUAL MODE R-GAIN B-GAIN  BACK  EXIT  SAVE & EXIT Figure 3-7 MANUAL MODE BRIGHTNESS Brightness refers to the brightness of the image. You can set the brightness value from 1 to 9 to darken or brighten the image. The higher the value is, the brighter the image is.
  • Page 16: Motion Det

    MOTION DET  Figure 3-8 MOTION Select a MOTION area. Set the MODE as ON. Click the up/down/left/right button to define the position, and the size of the area. Set the SENSITIVITY from 1 to 9. PRIVACY The privacy mask allows you to cover certain areas which you don’t want to be viewed, or recorded.
