TURBO HD
C5T Series Dome & Turret
Camera
User Manual
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Model
Type I Camera
DS-2CE5AC5T-AVPIT3Z
Type II Camera
DS-2CE56C5T-IT3Z
Type III Camera
DS-2CE56C5T-IT3
This manual may contain technical incorrect places or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or
update the products or procedures described in the
manual.
0100001081115

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TURBO HD DS-2CE5AC5T-AVPIT3Z and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HIKVISION TURBO HD DS-2CE5AC5T-AVPIT3Z

  • Page 1 TURBO HD C5T Series Dome & Turret Camera User Manual User Manual Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Type Model Type I Camera DS-2CE5AC5T-AVPIT3Z...
  • Page 2 Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 4: Product Features

    1 Introduction 1.1 Product Features The main features are as follows: High performance CMOS sensor  IR cut filter with auto switch  OSD menu with configurable parameters  Auto white balance  SMART IR  3-axis adjustment  Wide dynamic range ...
  • Page 5: Installation

    2 Installation Before you start: Make sure that the device in the package is in good  condition and all the assembly parts are included. Make sure that all the related equipment is power-off  during the installation. Check the specification of the products for the ...
  • Page 6 Figure 2-3 Attach the Back Box Note: The supplied screw package contains self-tapping  screws, and expansion bolts. For cement ceiling, expansion bolts are required to  fix the camera. For wooden ceiling, self-tapping screws are required. 5. Route the cables through the cable hole, or the side opening.
  • Page 7 2.2 Ceiling Mounting of Type II Camera Before you start: The installation steps of ceiling mounting and wall mounting are similar, and the following takes ceiling mounting as an example to describe the steps. Steps: 1. Paste the drill template to the place where you want to install the camera.
  • Page 8 Figure 2-10 Install the Turret Camera 7. Tighten the screws with the screw driver. 8. Connect the corresponding cables, such as power cord, and video cable. 9. Power on the camera to check whether the image on the monitor is gotten from the optimum angle. If not, adjust the camera according to the figure below to get an optimum angle.
  • Page 9 Note: Drill the cable hole, when adopting the ceiling outlet to route the cable 5. Attach the mounting base to the ceiling, and secure them with supplied screws Figure 2-14 Attach the Mounting Base to the Ceiling Note: The supplied screw package contains self-tapping ...
  • Page 10: Menu Description

    3 Menu Description Please follow the steps below to call the menu. Note: Menu description part is only for your reference. It might have some differences due to the specific model that you have. Steps: 1. Connect the camera with the TVI DVR, and the monitor, shown as the figure 3-1.
  • Page 11: Slow Shutter

    5. Click the direction arrow to control the camera. (1) Click up/down direction button to select the item. (2) Click Iris + to confirm the selection. (3) Click left/right direction button to adjust the value of the selected item. 3.1 VIDOE FORMAT You can set the video format as 720P@25fps, or 720P@30fps.
  • Page 12 SLOW SHUTTER SLOW SHUTTER increases the exposure time on a single frame, which makes a camera more sensitive to the light so it can produce images even in low lux conditions. You can set the SLOW SHUTTER function as OFF, x2, x4, x6, x8, x10, x12, x14, or x16 according to the different light conditions.
  • Page 13: Video Settings

     IR LIGHT You can turn on/off the IR LIGHT to meet the requirements of different circumstances.  SMART IR The Smart IR function is used to adjust the light to its most suitable intensity, and prevent the image from over exposure.
  • Page 14: Motion Detection

    WHITE BALANCE MANUAL MODE R-GAIN B-GAIN  BACK  EXIT  SAVE & EXIT Figure 3-7 MANUAL MODE BRIGHTNESS Brightness refers to the brightness of the image. You can set the brightness value from 1 to 9 to darken or brighten the image. The higher the value is, the brighter the image is.
  • Page 15: Motion Det

    MOTION DET  Figure 3-8 MOTION Select a MOTION area. Set the MODE as ON. Click the up/down/left/right button to define the position, and the size of the area. Set the SENSITIVITY according to your needs. PRIVACY The privacy mask allows you to cover certain areas which you don’t want to be viewed, or recorded.
