U7T Series Turret & Dome
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Type I Camera
Type II Camera
Type III Camera
This manual may contain technical incorrect places or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or update
the products or procedures described in the manual.
TURBO HD
User Manual
Model
DS-2CE78U7T-IT1F
DS-2CE78U7T-IT3F
DS-2CE76U7T-ITMF
DS-2CE57U7T-VPITF
Camera
0100001081124
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HIKVISION DS-2CE78U7T-IT1F
Summary of Contents for HIKVISION DS-2CE78U7T-IT1F
- Page 1 Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Type Model DS-2CE78U7T-IT1F Type I Camera DS-2CE78U7T-IT3F Type II Camera DS-2CE76U7T-ITMF Type III Camera...
- Page 2 Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
- Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.
- Page 4 While in delivery, the camera shall be packed in its original packing, or packing of the same texture. Mark Description Table 0-1 Mark Description Mark Description DC Voltage 1 Introduction 1.1 Product Features The main features are as follows: IR cut filter with auto switch ...
-
Page 5: Installation
1.2.3 Overview of Type III Camera Video Cable Power Mounting Base Cord Switch Pan Adjusting Screw Button Tilt Adjusting Screw Bubble Safety Rope Figure 1-3 Overview of Type III Camera Note: Press and hold the switch button for 5 seconds to switch the video output. - Page 6 3. Paste the drill template (supplied) to the place where you want to install the camera. 4. Drill the screw holes and the cable hole (optional) on the ceiling/wall according to the drill template. Figure 2-2 Drill Template Note: Drill the cable hole, when adopting the ceiling outlet to route the cable 5.
- Page 7 Figure 2-5 3-axis Adjustment 1). Hold the camera body and rotate the enclosure to adjust the pan position [0° to 360°]. 2). Move the camera body up and down to adjust the tilt position [0° to 75°]. 3). Rotate the camera body to adjust the rotation position [0°...
- Page 8 Figure 2-8 Secure the Mounting Base to the Ceiling Note: The supplied screw package contains self-tapping screws, and expansion bolts. For cement wall/ceiling, expansion bolts are required to fix the camera. For wooden wall/ceiling, self-tapping screws are required. 6.
- Page 9 2.3 Ceiling Mounting of Type III Camera Steps: 1. Paste the dill template to the ceiling. 2. Drill the screw holes and cable hole (optional) in the ceiling according to the drill template. Figure 2-11 Drill Template Note: Cable hole is required, when adopting the ceiling outlet to route cables.
- Page 10 1). Loosen the tilt adjusting screw to adjust the tilt position [0° to 75°]. 2). Hold the black liner to adjust the pan position [0° to 355°]. 3). Hold the camera body to adjust the rotation position [0° to 355°]. 8.
-
Page 11: Menu Description
3 Menu Description Please follow the steps below to call the menu. NOTE: Menu description part is only for your reference. It might have some differences due to the specific model that you have. Steps: 1. Connect the camera with the TVI DVR, and the monitor, shown as the figure 3-1. -
Page 12: Video Format
3). Click left/right direction button to adjust the value of the selected item. 3.1 VIDEO FORMAT You can set the video format as 8MP@12.5 fps, 8MP@15fps, 5MP@20fps, 4MP@25fps, 4MP@30fps, 1080P@25fps, and 1080P@30fps. Note: When switching the video output as CVBS, you can ... - Page 13 COLOR The image is colored in day mode all the time. B & W (Black and White) The image is black and white all the time, and the IR LIGHT turns on in the poor light conditions. You can turn on/off the IR LIGHT and set the value of SMART IR in this menu DAY/NIGHT B &...
-
Page 14: Video Settings
the value from 1 to 9. The larger the value is, the more sensitive the camera is. 3.4 VIDEO SETTINGS Move the cursor to VIDEO SETTINGS and click Iris+ to enter the submenu. IMAGE MODE, WHITE BALANCE, BRIGHTNESS, CONTRAST, SHARPNESS, SATURATION, 3DNR, and MIRROR are adjustable. -
Page 15: Factory Default
SHARPNESS Sharpness determines the amount of detail an imaging system can reproduce. You can set the SHARPNESS value from 1 to 9. SATURATION Adjust this feature to change the saturation of the color. The value ranges from 1 to 9. 3 DNR (3D DNR) 3 DNR refers to 3D digital noise reduction.
