Assembly; Machine Specifications; Tools Required; Assembly Procedure - CYBEX Eagle Back Extension Owner's Manual

Machine Specifications

Total Weight and Size: Eagle 11100 Back Extension
Weight
658 lbs 47" W x 54" L x 58" H
298.46 kg 119.38 cm W x 137.16 cm L x 147.32 H 119.38 cm W x 139.7 cm L x 147.32 H
The dimensions stated in the installation instructions are the recommended minimum dimensions as
set forth by the manufacturer. The actual area for access and passage shall be the responsibility of
the facility and should take into account any required local codes or regulations.

Tools Required

7/32" Allen wrench
•
3/4" Allen wrench
•
9/16" Wrench
•
3/4" Socket or wrench
•
External snap ring pliers
•
Phillips screwdriver
•
Medium weight automotive engine oil
•
Torque Wrench
•

Assembly Procedure

Two people will be required for this procedure.
Read and understand all instructions thoroughly before assembling this unit. Check all items
carefully. If there is damage, see the Customer Service section of this manual for proper procedure to
return, replace, or reorder parts.
It is the responsibility of the facility owner/owner of the equipment to ensure that there is appropriate
clearance around each machine to allow for safe use and passage.
Verify parts list shown below
Qty
4
Cybex Owner's Manual

Assembly

Machine Dimensions at Rest
Part Number
11090-392
Machine Dimensions at Use
47" W x 55" L x 58" H
Description
Foot pad
8
Diagram
