Machine Specifications

Total Weight and Size VR1 Arm Extension - Cable 13080 Standard Stack
Weight
376 Lbs
171 Kg
Total Weight and Size VR1 Arm Extension - Cable 13080 Light Stack
Weight
331 Lbs
150 Kg
Maximum User Weight
300 lbs/135kg

Choosing and Preparing a Site

Before assembling the unit, verify the chosen site meets the following criteria:
• Area is well lit and well ventilated.
• Surface is structurally sound and properly leveled.
• Free area for access to unit and emergency dismount. Minimum clearance is 23.6 inches (0.6 meters).
• Adjacent units may share the free area.
It is the responsibility of the facility owner/owner of the equipment to ensure that there is appropriate clearance
around each machine to allow for safe use and passage.
In compliance with the ADA (American Disabilities Act) there must be clear floor space of at least 30 by 48 inches
and be served by an accessible route for at least one of each type of exercise equipment. If the clear space is
enclosed on three sides (e.g., by walls or the equipment itself), the clear space must be 36 by 48 inches.

Assembly

Machine Dimensions at Rest
45" L × 43" W × 89" H
114 cm L × 110 cm W × 226 cm H
Machine Dimensions at Rest
45" L × 43" W × 89" H
114 cm L × 110 cm W × 226 cm H
Same
Same
Same
Same
Maximum Training Weight
Page 8 of 23
Machine Dimensions in Use
Machine Dimensions in Use
152.5 lbs/69 kg
