Daikin RXL-W Series Service Manual page 164

Troubleshooting for Outdoor Unit
Note(s)
OL (Q1M/Q1L) activating temperature: 130°C (266°F)
OL (Q1M/Q1L) recovery temperature: 95°C (203°F)
High pressure switch (S1PH) activating pressure: 602 psi (4.15 MPa)
High pressure switch (S1PH) recovery pressure: 464 psi (3.2 MPa)
Reference
Check No.01 Refer to P.186
Reference
Check No.12 Refer to P.189
Reference
Check No.13 Refer to P.190
Reference
Check No.14 Refer to P.192
159
SiUS092231E
Part 6 Service Diagnosis
