Description of the device
Features
The Showtec Phantom 575 Basic is a moving-head with high output and great effects.
• 16/26 DMX-control channels required
• Stylish housing
• Sharp optics
• Automatic Pan/Tilt correction
• Colourwheel 1 with 8 vivid colours + white
• Colourwheel 2 with 6 vivid colours, 2 color correction filters + white
• Interchangeable colors
• Static Gobowheel with 7 static gobos and open
• Rotating Gobowheel with 6 rotating gobos and open
• Interchangeable Gobosystem
• Gobo Shake Function
• DMX-control via standard DMX-controller
• Seamless Zoom (13-27 degrees)
• Built in Macro's via DMX
• DMX Focus
• 3 and 5 pin XLR connectors
• rotating 3-facet prism
• Bright LCD display
• User selectable pan/tilt ranges
• Basic(16CH) or Advanced (26CH) operating modes
• Lamp on/off via DMX
• Electronic Ballast
• Mounting System: Quick-lock brackets and M10 nuts
• Mechanical Dimmer/Shutter/Strobe
• Strobe-effect with adjustable speed (1 - 10 flashes/sec.)
• Pan 0º -- 540º
• Tilt 0º -- 270º
• Lamp HMI 575 (ordercode 80901O)
• Fuse T7A / 250V
1
Overview
Fig. 1
1) Lens
