DMX Protocol 26 Channels (ADVANCED)
Channel 1 - Horizontal movement (Pan)
Push the slider up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 540° and stopped at any position you wish.
Channel 2 - Pan fine 16 bit
Channel 3 - Vertical movement (Tilt)
Push the slider, up in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 270° and stopped at any position you wish.
Channel 4 - Tilt fine 16 bit
Channel 5 –PAN/TILT Speed
0-255
Channel 6 –PAN/TILT Macro
0-255
Channel 7 – Shutter / Strobe (Dimmer must be open
0-3
4-7
8-127
128-191
192-223
224-251
252-255
Channel 8 – Shutter Macro
0-31
32-63
64-95
96-127
128-159
160-191
192-223
224-255
Channel 9 – Dimmer intensity
0-255
Channel 10 – Dimmer Fine
From Max Speed (0) to Min. Speed (255)
Pan/Tilt Built-in Programs
Shutter closed / Blackout
Shutter open
Strobe effect, from slow to fast (0-10 flashes/sec.)
Pulse-effect, in sequences from slow to fast
Shutter Effect
Random strobe effect, from slow to fast
Shutter open
No Function
Blackout during Pan/Tilt movement
Blackout during Static/Rot. Gobowheel movement
Blackout during Pan/Tilt or Static/Rot. Gobowheel movement
Blackout during Colorwheel 1+2 movement
Blackout during Pan/Tilt or Colorwheel 1+2 movement
Blackout during Static/Rot. Gobowheel or Colorwheel 1+2 movement
Blackout during Pan/Tilt, Static/Rot. Gobowheel or Colorwheel 1+2
From black to brightest
)
