Summary of Contents for SHOWTEC EventBAR 50IR
- Page 1 MANUAL ENGLISH EventBAR 50IR Ordercode: 44102 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Charging the built in battery ............................10 Control Modes ................................10 One EventBAR 50IR (Manual control) ........................10 One EventBAR 50IR (Built-in programs, Auto Run) .....................10 One EventBAR 50IR (Sound-control) ........................11 Multiple EventBARs 50IR (Master/Slave control) ....................11 Multiple EventBARs 50IR (DMX512 Mode) ......................12 Fixture Linking ................................13... - Page 3 EventBAR 50IR Troubleshooting ................................24 No Light ..................................24 No Response to DMX ..............................25 Product Specifications ..............................26 Dimensions ..................................27 Notes ....................................28 Ordercode: 44102...
-
Page 4: Warning
Save the carton and all packing materials. In the event that the fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: Showtec EventBAR 50IR • 2 brackets and screws • IEC powercable 1,5m •... - Page 5 For replacement, use fuses of same type and rating only. The user is responsible for correct positioning and operating of the EventBAR 50IR. The manufacturer will not accept liability for damages caused by the misuse or incorrect installation of this device.
-
Page 6: Operating Determinations
Always let the installation be carried out by an authorized dealer! Procedure If the EventBAR 50IR is lowered from the ceiling or high joists, professional trussing systems have to be used. Use a clamp to mount the EventBAR 50IR, with the mounting-bracket, to the trussing system. -
Page 7: Connection With The Mains
EventBAR 50IR The EventBAR 50IR can be placed on a flat stage floor or mounted to any kind of truss by a clamp. Improper installation can cause serious injuries and/or damage of property! Connection with the mains Connect the device to the mains with the power plug. -
Page 8: Return Procedure
EventBAR 50IR Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. -
Page 9: Description Of The Device
Description of the device Features EventBAR 50IR is a LED bar from Showtec. It is a very versatile and inexpensive batten effect for all sorts of locations and applications. • LEDs: 120 RGB high intensity 10mm LEDs (Red 48, Green 36, Blue 36) •... -
Page 10: Overview
EventBAR 50IR Overview Fig. 01 01) Adjustment screw + mounting bracket for Truss mounting 02) 120 RGB high intensity 10mm LEDs Backside Fig. 02 03) IEC Power In + Fuse T1AL / 250V 04) Ground/Earth connection 05) Ground/Earth connection 06) Power Switch On/Off... -
Page 11: Installation
EventBAR 50IR Installation Remove all packing materials from the EventBAR 50IR. Check that all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. Always disconnect from electric mains power supply before cleaning or servicing. -
Page 12: One Eventbar 50Ir (Sound-Control)
EventBAR 50IR One EventBAR 50IR (Sound-control) 01) Fasten the effect light onto firm trussing or place it on the floor. Leave at least 0,5 meter on all sides for air circulation. 02) When the EventBAR is not connected by a DMX-cable, it functions as a stand-alone device. -
Page 13: Multiple Eventbars 50Ir (Dmx512 Mode)
EventBAR 50IR Multiple EventBARs 50IR (DMX512 Mode) 01) Fasten the effect light onto firm trussing or place it on the floor. Leave at least 0,5 meter on all sides for air circulation. 02) Plug the end of the electric mains power cord into a proper electric power supply socket. -
Page 14: Fixture Linking
The EventBAR 50IR uses up to 12 channels. Important: Fixtures on a serial data link must be daisy-chained in a single line. To comply with the EIA-485 standard, no more than 30 devices should be connected on one data link. -
Page 15: Control Panel
EventBAR 50IR Control Panel A. LED Display B. Mode button C. Setup Button D. Up Button E. Down Button Fig. 05 DMX Control Mode The fixtures are individually addressed on a data-link and connected to the controller. The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it, the controller will display the saved DMX address the next time.) -
Page 16: Menu Overview
EventBAR 50IR Menu overview Ordercode: 44102... -
Page 17: Main Menu Options
Settings Auto Run Program With this menu you can set the Auto run mode of the EventBAR 50IR. 01) Press the Mode button on the device, until the display shows 02) The EventBAR will start automatically with its auto program. -
Page 18: Master / Slave Addressing
EventBAR 50IR 05) Press the Mode button to go back to 06) With the Up and Down buttons you can choose between 07) Press the Setup button to set the speed or strobe value. 08) Use the Up and Down buttons to set the speed and strobe value between 0-99 or SPFL. -
Page 19: Sound Control Mode
02) Press the Setup button to see the energy level in %, from 0 - 100%. Settings With this menu you can set the EventBAR 50IR to its economy mode. 01) Press the Mode button, until the display shows 02) Use the Up and Down buttons to choose between normal mode and economy mode. -
Page 20: Optional Remote Control
EventBAR 50IR Optional remote control Button Function Description On / Off Switch the device ON or OFF Auto Mode Activate Built-in Auto Show mode Program Mode Activate Built-in Programs Show mode Sound-controlled Mode Activate Sound-controlled mode Speed Mode Activate Speed mode... -
Page 21: Built-In Auto Show
EventBAR 50IR Button Function Description Purplish red Activate the Purplish red color Orange Activate the Orange color White Activate the White color Bright pink Activate the Bright pink color Light green Activate the Light green color Water blue Activate the Water blue color... -
Page 22: Dmx Channels
EventBAR 50IR DMX Channels 2 DMX Channels Channel 1 – Built-in Programs 0-11 Program 01 12-23 Program 02 24-35 Program 03 36-47 Program 04 48-59 Program 05 60-71 Program 06 72-83 Program 07 84-95 Program 08 96-107 Program 09 108-119... -
Page 23: Dmx Channels
EventBAR 50IR Channel 4 – Shutter / Strobe (CH1, CH2, CH3 or CH5 must be set between 001-255 0-255 Strobe (0-20Hz, color strobe selected by CH1-CH3) Channel 5 – Dimmer 0-255 Gradual adjustment, from dark to brightest 0-100% Channel 6 – Built-in Programs (CH5 must be set between 001-255... -
Page 24: Dmx Channels
EventBAR 50IR 5 DMX Channels Channel 1 – Red Dimmer intensity (CH4 must be set between 001-255 0-255 Gradual adjustment Red from 0 – 100% Channel 2 – Green Dimmer intensity (CH4 must be set between 001-255 0-255 Gradual adjustment Green from 0 – 100% Channel 3 –... -
Page 25: Maintenance
04) The electric power supply cables must not show any damages or material fatigue. The Showtec EventBAR 50IR requires almost no maintenance. However, you should keep the unit clean. Otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power supply and then wipe the cover with a damp cloth. -
Page 26: No Response To Dmx
EventBAR 50IR No Response to DMX Response: Suspect the DMX cable or connectors, a controller malfunction, a light effect DMX card malfunction. 01) Check the DMX setting. Make sure that DMX addresses are correct. 02) Check the DMX cable: Unplug the unit; change the DMX cable; then reconnect to electrical power. -
Page 27: Product Specifications
EventBAR 50IR Product Specifications Model: Showtec EventBAR 50IR Input Voltage: 100-240V AC, 50/60Hz Consumption Power 22 Watt DMX linking: 30pcs Fuse: T1AL / 250V Dimensions: 570 x 70 x 135 mm (LxWxH) (incl. brackets) Weight: 1,84 kg Operating and Programming:... -
Page 28: Dimensions
EventBAR 50IR Dimensions Ordercode: 44102... -
Page 29: Notes
EventBAR 50IR Notes Ordercode: 44102... - Page 30 EventBAR 50IR Ordercode: 44102...
- Page 31 EventBAR 50IR Ordercode: 44102...
- Page 32 ©2016 Showtec...
