MTCAP-915-001

Note:
Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into the power source
when determining product load.
Maximum Power: MTCAP LoRa connection to MTXDOT running TXP =20 and at+txdr=2. The
MTXDOT was initialized to send packets by joining MTCAP and rapidly sending packet to the MTCAP.
Tx Pulse: The average peak current.
Inrush Charge: The total inrush charge at power on.
Idle Current
5.0 Volts
128 mA
® TM
MultiConnect Conduit
Average Measured Current
at Maximum Power
397 mA
AP MTCAP-LNA3-915 and MTCAP-915 User Guide
CHAPTER 2 SPECIFICATIONS AND HARDWARE INFORMATION
TX Pulse Peak Current for no
radio model
524 mA
Total Inrush Charge
Measured in Millicoulomb
1.33 mC
11
