Rimage DL5200/DLN5200 User Guide

Operate Gemini Utilities

The Rimage Producer Software Suite includes an application called Gemini Utilities, which is used to update
the autoloader firmware. It may also be used to change the display name of the Rimage DL5200/DLN5200
and to enable the beeper. The Rimage DLN5200 displays the computer name on the operator panel. The
computer name is helpful when identifying the computer on the network.
Tip: To access Gemini Utilities on a DLN5200, use the remote desktop connection from a networked
PC, or connect a monitor, keyboard, and mouse to the DLN5200.

Start Gemini Utilities

1. Close all applications.
2. In Rimage Service Manager, stop all Rimage
Services.
Note: Refer to your Rimage Software online help
for additional information.
3. Navigate: Start > Programs > Rimage > Utilities >
Gemini Utilities. Gemini Utilities opens.
Note: When the desired tasks are complete,
restart the Rimage Services.

Change the autoloader display name

Use Gemini Utilities to enter the name displayed on the operator panel.
1. Select the Override Name checkbox.
2. Clear the Use Computer Name checkbox.
3. In the Display Name field, enter the new name.
4. Select Set DiscLab Params to save the settings.

Enable the beeper

You can change the number of beeps that occur when there is an error.
1. In the # of Beeps on Fault field, select or enter the number of beeps you wish to hear when there is an
error.
Tip: Entering 0 (zero) in the # of Beeps on Fault field disables the beeper.
2. Select Set DiscLab Params to save the settings.

Stop Gemini Utilities

Select Exit to close Gemini Transporter Utilities.
18 110768_F
