3. Place the discs in the input bin with the
recording side facing down.
Important! Hold the discs by the edge.
Fingerprints affect print quality.
4. Place the input bin on the base plate.
5. Rotate the input bin until it drops into the
notches.
6. Close the supply door.

Remove or Install the Front Panel

Remove the front panel

Grasp the sides of the front panel and pull out.
Note: The front panel has four pins
that are held in with retaining clips.

Install the front panel

Align the pins to the retaining clips and press into
place.
110768_F
Operate the Rimage DL5200/DLN5200
Notch
Front Panel
Input Bin
Base Plate
13
