Vacuum Floor Stand & Accessory Holder
Designed for Dyson Vacuums
Instruction Manual
SKU: LF-VFS1A
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://lifefinds.store/products/lf-vfs1a
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@lifefinds.store
www.lifefinds.store
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the life finds LF-VFS1A and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo life finds LF-VFS1A

  • Page 1 Vacuum Floor Stand & Accessory Holder Designed for Dyson Vacuums Instruction Manual SKU: LF-VFS1A Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://lifefinds.store/products/lf-vfs1a GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@lifefinds.store www.lifefinds.store 309-278-5303...
  • Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3 ASSEMBLY OPTION A: Free-Standing Option STEP 1 Assemble Upper and Lower Poles (B,D) onto Middle Pole (C) using M5x8mm Round Head Screws (S-C) and 3mm Allen Wrench (T-B). STEP 2 Attach Base (A) to Lower Pole (D) using M5x20mm Screws (S-B) and 3mm Allen Wrench (T-B). STEP 3 Attach Adapter Plate (E) to Upper Pole (B) using M5x8mm Flat Head Screws (S-A) and 3mm Allen Wrench (T-B).
  • Page 4 STEP 4 Attach the Dyson Docking Station that came with your Dyson vacuum to Adapter Plate (E) using M5x16mm Screws (S-D), M5 Nuts (S-E), and a Phillips Screwdriver. Dyson Docking Station STEP 5 Press Accessory Clips (F) onto the assembled pole set. Route the power cable from the docking station through the back of the stand.
  • Page 5 STEP 6 Loosen screws on Accessory Extension (G) using 2.5mm Allen Wrench (T-A) so that the red lock adapters are able to slide freely. STEP 7 Install Accessory Extension (G) onto the Dyson Docking Station and re-tighten screws using 2.5mm Allen Wrench (T-A).
  • Page 6 ASSEMBLY OPTION B: Wall Mount WOOD STUD INSTALLATION Hold the Dyson Docking Station that came with your Dyson vaccum against the wall with the lower hole positioned 47 1/4” (120cm) off the ground. Mark drilling locations with a pencil. Use of a level and stud finder is highly recommended.
  • Page 7 CONCRETE/BRICK INSTALLATION Hold the Dyson Docking Station that came with your Dyson vacuum against the wall with the lower hole positioned 47 1/4” (120cm) off the ground. Mark drilling locations with a marker. Use of a level is highly recommended. Make sure there is an outlet near your chosen installation location. Drill 1.4”...
  • Page 8 LAST UPDATED: 05/10/2023 REV1 Open Monday - Friday 7:00am - 7:00pm CST, our dedicated support team can offer immediate assistance with rapid response times. If any parts are received damaged or defective, please contact us. We are happy to replace parts to ensure you have a fully functioning product.
