EK-Quantum Vector FTW3 RTX 3080Ti User Manual page 8

M4 x 27 DIN7984
SCREW
FC TERMINAL
OR 15 x 1 mm
EK-Quantum Vector FTW3 RTX 3080/3090 Active Backplate comes
with its own terminal, meaning the original terminal, along with two
(2) 15x1 O-rings, on the EK-Quantum Vector FTW3 3080/3090
water block has to be removed.
Unscrew the three (3) M4 x 27 DIN7984 screws and detach the
terminal from the water block.
The procedure of the terminal detachment is shown below.
For this Step, you will need:
STEP 1
- 8 -
Attention!
In case the EK-Quantum Vector FTW3 RTX 3080/3080Ti/3090
water block is already filled with coolant, empty the content of
the water block before continuing with this step. Be careful that
the coolant that remained in the water block does not come in
contact with the GPU!
Allen Key 2.5 mm
