- Page 1 User Manual PPC-IPS Intelligent Power System for PCs...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 Technical Support and Assistance Visit the Advantech web site at http://support.advantech.com where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
- Page 4 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
- Page 5 Battery Information Batteries, battery packs, and accumulators should not be disposed of as unsorted household waste. Please use the public collection system to return, recycle, or treat them in compliance with the local regulations. 。 PPC-IPS User Manual...
- Page 6 PPC-IPS User Manual...
-
Page 7: Table Of Contents
Replace the IPS Battery.............. 19 Figure 2.24Top cover screw positions ........19 Figure 2.25Open IPS Power connector position......19 Chapter IPS Setting Informations ....21 Supplementary I/O Connector Instructions ..........22 PS_ON shut down mode setting ............. 23 Chapter PPC-IPS-AE Adjustment Tool...27 PPC-IPS User Manual... - Page 8 UI Introduction - Base ................29 4.2.1 Select COM Port................. 29 4.2.2 Power State Selection (S4 or S5) ..........29 4.2.3 PPC-IPS Status ................29 4.2.4 Final Countdown for Shutdown........... 30 4.2.5 Operating Temp. for Battery Pack ..........30 4.2.6 Max.
-
Page 9: Chapter 1 General Information
Chapter General Information This chapter gives background information on the PPC-IPS. Sections include: Introduction Specifications Dimensions... -
Page 10: Introduction
This product is intended to be supplied by a Listed Power Adapter or DC power source, rated 12-30V , 8.5-3.5A minimum and Tma 50 degrees Celsius, if need further assistance with purchasing the power source please contact Advantech for further information. PPC-IPS User Manual... -
Page 11: Dimensions
3.60 104.67 Figure 1.1 Dimensions includes baseboard Max. depth for VESA mounting screws is M4*8 (mm) 151.80 32.00 100.00 75.00 DC OUT DC IN BAT Charge BAT Active 30s / 360s DC-IN Figure 1.2 Dimensions without baseboard PPC-IPS User Manual... - Page 12 Figure 1.3 Install with din-rail bracket 66.00 9.00 35.00 Figure 1.4 Din-rail bracket dimensions PPC-IPS User Manual...
-
Page 13: Chapter 2 Installation Instructions
Chapter Installation Instructions... -
Page 14: Introduction
PC. There are two modes for setting IPS shutdown PC: PS-ON or RS232. Refer to the figure below for a description of the connection. Note! Customers can choose either the model based on their installation requirements. PPC-IPS User Manual... - Page 15 Doesn’t need to occupy RS- Status monitoring * For Max. mode, it has the PPC-IPS-AE to supply longest power according to the system power consumption and battery capacity presently. A. PS_ON Mode Connect PS_ON wire of control cable to PPC MB's PS_ON slot.
-
Page 16: A Quick Tour
PPC-IPS Shutdown Signal Diagram A Quick Tour Before setting up the PPC-IPS, take a moment to become familiar with the locations and purposes of controls, connectors and ports, illustrated in the figures below. When placed upright on the desktop, the PPC-IPS appears as shown in Figure 2.3. - Page 17 A. System reset B. Status indicators C. RS-232 (for connecting a PC) D. PS_ON (to shut down PC) E. Time switch (for setting auto shutdown) F. DC out (2 pins) G. DC input (2 pins) H. Grounding PPC-IPS User Manual...
-
Page 18: Installation Procedures
Installation Procedures 2.3.1 VESA Mount Installation First assemble VESA bracket on PPC, then install PPC-IPS following figures. Figure 2.3 Mounting Diagram Note! Max. depth for VESA mounting screws is M4*8 (mm). 2.3.2 DIN-rail Installation The other method of installing the IPS is to install it on a DIN-rail. Take the DIN rail bracket and screws from the accessory bag, attach as below. -
Page 19: Power Cable & Control Cable Installation
Panel PC as a loading machine. If customers use another PC as a loading machine, install the Power cable and PS_ON cable according to the other machines connector pin definitions. 2.3.3.1 Making the Power cable Take the power cable from the accessory bag. Figure 2.6 Power Cable Photo PPC-IPS User Manual... - Page 20 As shown in the figure below, the white wire is the positive pole of the adapter, and the black wire is the negative pole. Figure 2.8 Positive and negative cables Fasten power cable screw and finish making the power cable. Figure 2.9 Power cable and adaptor finished PPC-IPS User Manual...
- Page 21 Making the Control cable (depends on shut down mode) A. Shut down through PS_ON by Hardware Signal The the control cable from accessory bag Figure 2.10 Control cable photo Remove the left side COM port cable. Figure 2.11 COM port cable PPC-IPS User Manual...
- Page 22 Release the screws on the rear cover and open it. Figure 2.12 Screw positions Break the punch hole on the rear cover. Figure 2.13 Punch hole positions PPC-IPS User Manual...
- Page 23 PS_ON single port on M/B. Figure 2.14 Feeding the cable through the punch hole Close the rear cover and tighten the screws. Figure 2.15 Finished power cable Refer to chapters 2.4.1 or 2.4.2 to install IPS by VESA or Din-rail. PPC-IPS User Manual...
- Page 24 PS_ON shut down mode need set power button as shutdown or sleep, refer to Chapter 3 for settings. B. Shut down through RS-232 by Software Utility Take the control cable from the accessory bag. Figure 2.17 RS-232 cable Remove the right side PS_ON wire. PPC-IPS User Manual...
- Page 25 Refer to chapters 2.4.1 or 2.4.2 to install IPS by VESA or DIN-rail. Connect the power cable and control cable to the PC. Figure 2.19 Connecting the power and control cables Note! This mode needs a pre-installed IPS APP, refer to Chapter 4 for APP detail setting. PPC-IPS User Manual...
-
Page 26: Ips Installation (Vesa Mount As Example)
Figure 2.20 Screw positions Remove the IPS baseboard. Figure 2.21 IPS baseboard Take the 4 screws from the accessory bag and use them to install the base- board on the back of the PC. Figure 2.22 Screw position PPC-IPS User Manual... -
Page 27: Replace The Ips Battery
Open the top cover, remove the cable connector and pick up the battery. Take a new battery replace it, then insert the battery cable connector, and secure the top cover. Figure 2.25 Open IPS Power connector position PPC-IPS User Manual... - Page 28 PPC-IPS User Manual...
-
Page 29: Chapter 3 Ips Setting Informations
Chapter IPS Setting Informations... -
Page 30: Supplementary I/O Connector Instructions
The Time switch is used to set the waiting period (30s/360s) before sending the PS_ON signal to shut down PC after AC power is off. Warning! During this time the PPC-IPS will supply the PC with its battery to ensure the loading PC works properly. -
Page 31: Ps_On Shut Down Mode Setting
PPC-IPS interface: phoenix connected 5P 5.08 pitch Note! The RS-232 is used to control IPS by AP. If the user does not use AP to control IPS, the RS-232 should be left unconnected. Need to set PC PS_ON as shut down mode, and must ensure there’s no other program to interrupt when PS_ON single send out. - Page 32 Left click on “Control Panel” in “Start menu” Left click on “Hardware and Sound " in “Control Panel” PPC-IPS User Manual...
- Page 33 Left click on “Change what the power buttons do“ in “Hardware and Sound”. Left click on “Open” in “System Settings” PPC-IPS User Manual...
- Page 34 Left click on “Shut down” Left click on “Save changes” in “System Settings” Complete above steps, finish the setting. PPC-IPS User Manual...
-
Page 35: Chapter 4 Ppc-Ips-Ae Adjustment Tool
Chapter PPC-IPS-AE Adjustment Tool... -
Page 36: Notice Of Use
Please note this utility will check the PC system ID first. If the connected PC isn't in the supported list, this utility will close auto- matically. Note! If your PC is not a PPC-3000 series, contact Advantech for operating with other PC systems. 4.1.2 Operating System Setting Environment PPC-IPS-AE Adjustment Tool supports Windows XP/7/8/8.1. -
Page 37: Ui Introduction - Base
Host PPC: indicate if AP connects with PPC correctly or not. DC-in: represent the DC power source for IPS is normal or not. Battery: represent the battery of IPS is working normally or not. PPC-IPS User Manual... -
Page 38: Final Countdown For Shutdown
4.2.4 Final Countdown for Shutdown The PPC-IPS-AE will shutdown / hibernate your PC after this time counts down to zero. Note! This time can be adjusted between 5 to 360 seconds or maximum bat- tery supply time. Please refer to 4.3.1 and 4.3.2 for further settings. -
Page 39: Time To Shut-Down Pc After Power Outage
"Max" time to Shut-down PC after Power Outage If users check on this option, the Final Countdown Time for Shutdown will be dynamic with the battery discharge state. PPC-IPS-AE will turn off your PC as soon as the bat- tery reaches 15% or less of power capacity. - Page 40 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2015...
