LSG SPG-230 User Manual

Magnetic spin bike
Hide thumbs
Table of Contents

Advertisement

Quick Links

SPG-230
Magnetic Spin Bike
USER MANUAL
Product may vary slightly from the item pictured due to model upgrades.
Read all instructions carefully before using this product.
Retain this owner's manual for future reference.
NOTE:
This manual may be subject to updates or changes. Up to date manuals are available through our
website at www.lsgfitness.com.au

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPG-230 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LSG SPG-230

Summary of Contents for LSG SPG-230

  • Page 1 SPG-230 Magnetic Spin Bike USER MANUAL Product may vary slightly from the item pictured due to model upgrades. Read all instructions carefully before using this product. Retain this owner’s manual for future reference. NOTE: This manual may be subject to updates or changes. Up to date manuals are available through our...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Important Safety Instructions ....... 03 II. Care Instructions ..........04 III.

  • Page 3: Important Safety Instructions

    I. IMPORTANT SAFETY INSTRUCTIONS WARNING: Read all instructions before using this machine. It is important your machine receives regular maintenance to prolong its useful life. Failing to regularly maintain your machine may void your warranty. Please always keep this manual with you. •...

  • Page 4: Care Instructions

    • Always keep this instruction manual and assembly tools at hand for reference. • The equipment is not suitable for therapeutic use. • The pulse or heart rate sensors are not medical devices. Various factors, including the user’s movement, may affect the accuracy of heart rate readings. The pulse sensors are intended only as exercise aids in determining heart rate trends in general.

  • Page 5: Exploded Diagram

    III. EXPLODED DIAGRAM EXPLODED DIAGRAM |...

  • Page 6: Parts List

    IV. PARTS LIST Description Specs Description Specs Seat Saddle Main Frame Seat Post Back Stabiliser Feet Right Foot Pedal Vertical Seat Post Ф10 Flat Washer Handlebar Adjustment Tube Ф50x27.6xM10 Seat Adjustment Nut Handlebar Ф56x70xM16 Seat Adjustment Pull Pin Display Left Foot Pedal Bottle Holder Back Stabiliser Feet Power Adapter...

  • Page 7: Assembly Instructions

    V. ASSEMBLY INSTRUCTIONS A. Remove the Packaging from the Front Handlebar Tube. Packaging can be discarded. B. Remove the Packaging from the Bottom Feet. Packaging can be discarded. C. Remove Polyfoam from Flywheel D. Remove the Wood Blocks STEP 1 A.
  • Page 8 TOOL STEP 2 1. Use 4PCS M8x50 bolts, 4PCS M8 flat washers, and 4PCS M8 spring washers to fix the front and rear foot tube to the bottom feet as pictured. ATTENTION: Before starting assembly, please ensure that all packaging components have been disposed of and the wooden blocks for the flywheel is also removed.
  • Page 9 TOOL STEP 4 1. Identify between the Left and Right pedals from the labels on pedals. 2. Assemble the pedals, paying attention to keeping the pedals axis and crank perpendicular during assembly. Do not use tools yet, and tighten in the direction as shown in the figure. Once the thread on the foot pedal is basically screwed in, then tighten the foot pedal with a wrench.
  • Page 10 STEP 5 A. Insert the Vertical Seat Post into the main frame along the direction of the outer sleeve, and secure the Seat Adjustment Pull Pin in a suitable position for the user height. B. Place the Seat Post onto the Vertical Seat Post, paying attention to the position with round post at the front as pictured and secure it using an M10 flat washer and Seat Adjustment Nut.
  • Page 11 TOOL STEP 7 1. Use 4PCS M8x15 Hex socket head bolts, 4PCS M8 Spring washers, and 4PCS M8 Flat washers to install the armrest adjustment and armrest together. Tighten the bolts with an external hexagonal wrench. ASSEMBLY INSTRUCTIONS |...
  • Page 12 TOOL Adapter Plug STEP 8 1. Use a cross wrench to remove the cross-pan head tapping screw ST4.2x13 that is pre-installed on the Display. 2. Connect the meter wire and sensing wire, and then connect the heart rate wire. 3. After aligning the holes, place the Display on the armrest and use the same screws ST4.2x13 to install the Display to the mount.
  • Page 13 117.7cm 46.3" 106cm 41.7" 54.6cm 21.5" ASSEMBLED SIZE 106cm x 54.6cm x 117.7cm ASSEMBLY INSTRUCTIONS |...

  • Page 14: Moving The Spin Bike

    VI. MOVING THE SPIN BIKE 1. When moving the machine, grab the front end of the handle and push it downwards, so that the roller on the foot tube is fully in contact with the ground. Then, start moving the machine to the desired position and slowly let go.

  • Page 15: Seat And Handlebar Adjustments

    VII. SEAT AND HANDLEBAR ADJUSTMENTS SEAT ADJUSTMENTS Height Adjustment Fore/Backward Adjustment Rotate the adjusting pull pin counterclockwise Loosen the seat cushion adjustment knob, with one hand and pull it outward. Grasp the then slide the seat cushion back and forth to seat cushion with the other hand and pull it up the desired position, and then tighten the knob.

  • Page 16: Operation Guide

    VIII. OPERATION GUIDE KEY FUNCTIONS 1. When the machine is not powered on, the central control knob screen displays is not lit up (Fig. 1). 2. When the knob is powered on, the buzzer sounds once, and the screen is fully displayed (Fig. 2). After 2 seconds, it enters standby mode.
  • Page 17 FIG 3 FIG 4 FIG 5 FIG 6 FIG 7 FIG 8 FIG 9 During the movement process, the resistance segment can be adjusted by rotating the direction of the central control knob. • Clockwise rotation increases the resistance segment, with a maximum adjustment of 32 segments. •...
  • Page 18 DATA DISPLAY DESCRIPTION ITEM NAME WINDOW DISPLAY DESCRIPTION Distance 000.0~999.9 Time 00:00~99:59 Calorie 000.0~999.9 Cadence 10~200 Resistance 1-32 Calculated based on wheel diameter Speed (RPM=60 speed 21.5KM) Heart Rate 60-200 Display: Bluetooth connected Bluetooth Not displayed: Bluetooth not connected | OPERATION GUIDE...

  • Page 19: Exercise Guide

    IX. EXERCISE GUIDE PLEASE NOTE: Before beginning any exercise program, consult your physician. This is important especially if you are over the age of 45 or individuals with pre-existing health problems. The pulse sensors are not medical devices. Various factors, including the user’s movement, may affect the accuracy of heart rate readings.
  • Page 20 COOL DOWN Finish each workout with a light jog or walk for at least 1 minute. Then complete 5 to 10 minutes of stretching to cool down. This will increase the flexibility of your muscles and will help prevent post- exercise problems.

  • Page 21: Warranty

    X. WARRANTY AUSTRALIAN CONSUMER LAW Many of our products come with a guarantee or warranty from the manufacturer. In addition, they come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage.
